220V AC 50HZ Portable Temperature Calibrator For Human Body Thermometer

220V AC 50HZ Portable Temperature Calibrator For Human Body Thermometer

thermal shock test chamber

salt spray test chamber

Place of Origin:

CHINA

Brand Name:

YUYANG

Model Number:

YYD03

Contact Us
Request A Quote
Product Details
Power:
220V AC 50HZ
Measure Range:
30~50C
Cavity Diameter::
56mm
Application::
Infrared Thermometer
Emissivity:
≥0.99
Function:
Temperature Calibrator
Highlight:

thermal shock test chamber

,

salt spray test chamber

Payment & Shipping Terms
Minimum Order Quantity
1
Packaging Details
Wooden Box
Delivery Time
1-3 WORK DAYS
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
500 SETS A MONTH
Product Description

New Style Infrared Thermometer Calibration Instrument Blackbody Furnace



220V AC 50HZ Temperature calibrator High Quality Blackbody Calibrating For Human Body Thermometer



1. Product Description

A precision blackbody (black body) is a controlled source of thermal radiation used to calibrate infrared radiation thermometers (pyrometers), thermal imagers and radiation heat flux gauges and radiometers. It is our ZONHOW R&D and manufactured product which is special used in calibration for Infrared ear temperature gun, forehead temperature gun and medical thermometer. It can also be used for the calibration of infrared body surface screening instrument. Through our main R&D of the temperature cycle system, plus the new materials, the emissivity can reach more than 0.99.



2. Summary:

A precision blackbody (black body) is a controlled source of thermal radiation used to calibrate infrared radiation thermometers (pyrometers), thermal imagers and radiation heat flux gauges and radiometers. It is our ZONHOW R&D and manufactured product which is special used in calibration for Infrared ear temperature gun, forehead temperature gun and medical thermometer. It can also be used for the calibration of infrared body surface screening instrument. Through our main R&D of the temperature cycle system, plus the new materials, the emissivity can reach more than 0.99.



This black body source has been introduced to meet the demand for a simple, cost-effective, but high accuracy calibrator for the calibration of thermal imagers and infrared thermometers used at temperatures near ambient.

A 56mm diameter, ridged plate is heated or cooled with an internal solid-state thermoelectric heat pump. The temperature of the plate can be set from 30°C to 50°C, to a resolution of 0.01°C.





3. Specifications

Item Black Body Furnace for Calibration of Infrared Thermometer
Measure Range 30~50ºC adjustable
Temp Resolution 0.01ºC
Cavity Diameter Φ56mm
Cavity Depth 50mm
Emissivity ≥0.99
Temp Stability ±0.1ºC/30min
Temp Uniformity ±0.1C°
Power 220V AC 50HZ
Weight Approx 3.0Kg

220V AC 50HZ Portable Temperature Calibrator For Human Body Thermometer 0220V AC 50HZ Portable Temperature Calibrator For Human Body Thermometer 1220V AC 50HZ Portable Temperature Calibrator For Human Body Thermometer 2
