Easy Operate Environmental Test Chamber Electroplate Salt Spray Test Machine ASTM B117

Easy Operate Environmental Test Chamber Electroplate Salt Spray Test Machine ASTM B117

  • Easy Operate Environmental Test Chamber Electroplate Salt Spray Test Machine ASTM B117
  • Easy Operate Environmental Test Chamber Electroplate Salt Spray Test Machine ASTM B117
  • Easy Operate Environmental Test Chamber Electroplate Salt Spray Test Machine ASTM B117
  • Easy Operate Environmental Test Chamber Electroplate Salt Spray Test Machine ASTM B117
Easy Operate Environmental Test Chamber Electroplate Salt Spray Test Machine ASTM B117
Product Details:
Place of Origin: China
Brand Name: YUYANG
Certification: ISO: 3768, 3769, 3770; ASTM: 8117, B268
Model Number: YY1015
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Plywood Case
Delivery Time: 15-20 work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 2 sets per month
Contact Now
Detailed Product Description
Product Name: Environmental Test Chamber Usage: Salt Spray Test Chamber
Material: PVC Rigid Plastic Board Temperature Range: 35°C~55°C
Temperature Fluctuations: ≤±0 . 5°C Power Supply: AC380V, 50/60HZ
Brine Temperature: 35°C±1°C Spray Quantity: 1 . 0~2 . 0 Ml / 80cm2 / Hr
High Light:

sand and dust test chamber

,

salt spray test chamber

ASTM B117 Environmental Test Chambers for Electroplate Salt Spray Test Machine





Product introduction:



Salt spray test machine is applicable for various kinds material’s surface treatment , such as after coating , electroplate , inorganic and organic membrane dermails , negative pole with antirust oil treatment etc anti-corrosive treatment to test the corrosion-resistance of the product



Design standard :



CNS : 3627 , 3385 , 4159 , 7669 , 8886 ;

JIS : D0201 , H8502 , H8610 , K5400 , Z2371 ;

ISO : 3768 , 3769 , 3770 ;

ASTM : 8117 , B268 .





Control System:



High precision P . I . D . temperature control meter with its error ±0 . 1°C .





Purpose :



Salt spray test machine is applicable for the salt spray corrosive test for the protection layer of components , parts , electronic and electrical parts and metal materials and industrial products





Chamber Structure:



1 . Salt spray test machine cover is made of transparent materials so that the operator can see the tested sample in the chamber and the spraying situation of the tested sample .
2 . A waterproof structure is adopted between the chamber cover and chamber body and thus there is no salt spray overflow .
3 . Adopts the tower spraying system and equipped with the salt solution filter system and non-crystal nozzle so as to realize even salt spray distribution and freely adjustable settlement .





Main technical parameters :



Model YY1015-60 YY1015-90 YY1015-120
Inner box size :
( L×W×H ) cm
60×40×45 90×60×50 120×100×50
Outside box size :
( L×W×H ) cm
107×60×118 141×88×128 190×130×140
Equipment material : Both internal and external material is using imported P . V . C rigid plastic board ; the case cover is using transparent rigid plastic board P . V . C .
Temperature range : 35°C~55°C
Temperature fluctuations : ≤±0 . 5°C
Temperature uniformity : ≤±2°C
Temperature precision : ±1°C
Test chamber temperature NSS ACSS 35±1°C CASS : 50±1°C
Saturated air barrel temperature : NSS ACSS 47±1°C CASS 63±1°C
Brine temperature : 35°C±1°C
Spray quantity : 1 . 0~2 . 0 ml / 80cm2 / hr
PH : NSS ACSS6 . 5~7 . 2 CASS 3 . 0~3 . 2
Lab volume : 108L 270L 600L
Brine tank capacity : 15L 25L 40L
Power : 1AC220V , 10A 1AC220V , 15A AC 1 , 220V , 30A
Multiple safety protection devices : Water shortage/ over temperature / phase protection
Standard accessories : Test salt , measure bucket , tool etc 1 set





Specifications:



Salt Spray Corrosion Test Machine

1 . Durable hard PVC construction
2 . Anti-corrosion ,
3 . Easy clean & operate
4 . 1 years warranty





Features :



1 Durable hard PVC construction , anti-corrosion , easy to clean .

2 Reservoirs with mixing system on stand .

3 Cabinet heated by water jacket , heating element from USA famous company .

4 Separate heating system , be apart from salt testing chamber to ensure accurate result and protect circuit .

5 Exposure zone lined with corrosion-resistant PVC sheets .

6 Clear cover allows viewing of test conditions .

7 Peaked cover prevents dripping of condensation onto samples .

8 Water seal and water level protection system .

9 Heated humidifying tower with air relief valve , adjustable tower tip to orient salt fog .

10 Automatic DI water fill to humidifying tower .

11 Digital temperature control and readouts .

12 Integral over-protection on all heaters .

13 Low water cut-off protection on humidifying tower .
