YY1307Universal Tensile Testing Machine Stroke 1100 mm For Footwear / Leathers

YY1307Universal Tensile Testing Machine Stroke 1100 mm For Footwear / Leathers

  • YY1307Universal Tensile Testing Machine Stroke 1100 mm For Footwear / Leathers
  • YY1307Universal Tensile Testing Machine Stroke 1100 mm For Footwear / Leathers
  • YY1307Universal Tensile Testing Machine Stroke 1100 mm For Footwear / Leathers
  • YY1307Universal Tensile Testing Machine Stroke 1100 mm For Footwear / Leathers
YY1307Universal Tensile Testing Machine Stroke 1100 mm For Footwear / Leathers
Product Details:
Place of Origin: China
Brand Name: YUYANG
Certification: QB/T 2918-2007
Model Number: YY1307
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: plywood case
Payment Terms: Western Union, T/T, L/C,Paypal
Supply Ability: 3pcs /week
Contact Now
Detailed Product Description
Name: Universal Testing Machine Motor: AC Servo Motor
Communication Interface: USB Stroke Resolution: 0.00004 Mm
Test Speed: 0.0001~1000mm/min Sample Rate: 200 Times/sec
Weight: 300Kg
High Light:

textile lab equipment

,

universal testing machine

Universal Testing Stroke 1100 mm Selectable Resolution Tensile Testing Machine





Description:



tensile strength testing equipment  are widely applied to determining elongation,

compression, flexing,tear,peeling,shear force,adhesive force,etc.of finished or semifinished products such as rubber,plastic, footwear, leathers, metal,wire, paqer, timber,etc.





Specification:



Model

YY1307

Capacity (optional)

100, 200, 500 N; 1, 2, 5, 10, 20,30 kN

Unit (Switchable)

kgf, gf,, lbf, N, kN,MPa,Pa or by user`s definition

Load Resolution

1/200,000

Load Accuracy

±0.5%

Load Range

Rangeless (full scales at the same amplification)

Stroke (exclude the grips)

1100 mm

Effective width

400 mm

Test Speed

0.0001~1000mm/min

Speed Accuracy

±0.5%

Stroke Resolution

0.00004 mm

Sample Rate

200 times/sec

Communication Interface

USB

Display method

U62 Dedicated Software

Motor

AC servo motor

Dimension (WxDxH)

Main Unit (Height exclusive of footpad)

111 × 64 × 233 cm

Computer/Desk

109 × 65 × 116 cm

Weight (approx.)

Main Unit

263kg (excluding control cabinet and grips)

Computer/Desk

50kg

Power

1∮, 220V,50/60Hz,15A or specified by user







The accessories such as the different grips, elongation measuring-devices... etc. are



equipped according to the requirements specified in the contract; our sales



representative will also give the proper suggestions to our customer beforehand.
