AC 220V 3A Footwear Testing Equipment / Leather Friction Testing Machine 150±5 RPM

China AC 220V 3A Footwear Testing Equipment / Leather Friction Testing Machine 150±5 RPM supplier
AC 220V 3A Footwear Testing Equipment / Leather Friction Testing Machine 150±5 RPM supplier AC 220V 3A Footwear Testing Equipment / Leather Friction Testing Machine 150±5 RPM supplier AC 220V 3A Footwear Testing Equipment / Leather Friction Testing Machine 150±5 RPM supplier AC 220V 3A Footwear Testing Equipment / Leather Friction Testing Machine 150±5 RPM supplier

Large Image :  AC 220V 3A Footwear Testing Equipment / Leather Friction Testing Machine 150±5 RPM

Product Details:

Place of Origin: CHINA
Brand Name: YUYANG
Certification: BS-1006、BS-3144、BS-4060、BS-3424
Model Number: YYX-008

Payment & Shipping Terms:

Packaging Details: wooden carton
Delivery Time: 30-50 work days
Payment Terms: L/C, T/T
Supply Ability: 100 Sets Per Month
Contact Now
Detailed Product Description
Weight: 24.5±0.5N 7.1±0.2N Friction Shaft Speed: 150±5 RPM
Metal Sheet: 75X65X5mm Dimension: 260×380×490 Mm(L×W×H)
Power: 1∮﹐AC220V﹐3A Standard: BS-1006、BS-3144、BS-4060、BS-3424



AC 220V 3A Footwear Testing Equipment / Leather Friction Testing Machine 150±5 RPM



Detailed Descriptions:



Leather friction testing machine is used to test the shoes leather or synthetic leather lining layer etc. after friction damage and the degree of discoloration. Can also be used to assess material on the surface of printing label font wear-resistant rub fastness. This machine has a dry, wet two testing ways.





Specifications
1.Specimen:60(w)*60mm(L) or diameter 60mm
2.Wool felt pad :outside dia.25±1mm, bore dia.3±0.5mm
6.5±0.5mm or 5.0±0.5mm(D) density 190±20kg/m³
3.Load :24.5±0.5N or 7.1±0.2N
4.Rotating Felt Pad Speed :150±5 rev/min
5.Metal Plate:75(L)*65(W)*5(D)mm, with a center hole diameter 25mm
6.Aluminium disk : diameter 50*12mm(D)
7.Dimension(W*D*H) :26*38*49cm
8.Weight:34kg
9.Power: AC 220V 3A



Specimen 60(w)*60mm(L) or diameter 60mm
Wool felt pad outside dia.25±1mm, bore dia.3±0.5mm
6.5±0.5mm or 5.0±0.5mm(D) density 190±20kg/m³
Load 24.5±0.5N or 7.1±0.2N
Rotating Felt Pad Speed 150±5 rev/min
Metal Plate 75(L)*65(W)*5(D)mm, with a center hole diameter 25mm
Aluminium disk diameter 50*12mm(D)
Dimension(W*D*H) 26*38*49cm
Weight 34kg
Power AC 220V 3A



AC 220V 3A Footwear Testing Equipment / Leather Friction Testing Machine 150±5 RPMAC 220V 3A Footwear Testing Equipment / Leather Friction Testing Machine 150±5 RPM
