Product Details:
Place of Origin: china
Brand Name: YUYANG
Certification: ISO-14616-1997, DIN 53369-1976
Model Number: YYP-009
Payment & Shipping Terms:
Packaging Details: Veneer Case
Delivery Time: 3-5 work days
Supply Ability: 30 Sets/month
Contact Now
Detailed Product Description
Capacity Range: 0.2 ~ 30 N (standard) Customization Available Accuracy: ±0.2%
Displacement Range: 0.125 ~ 70 Mm Temperature Range: Room Temperature ~ 210°C
Number Of Specimens: 1 ~ 3 Groups Specimen Size: 130 Mm X 15 Mm (Standard)
Gas Supply: Dry Air (outside Of Supply Scope) Port Size: Φ6 Mm PU Tubing
Instrument Dimension: 735 Mm (L) X 490 Mm (W) X 391 Mm (H) Power Supply: 220VAC 50Hz / 120VAC 60Hz
High Light:

packaging testing instruments

,

compression test equipment



ISO-14616-1997 Food Package Wrapping Heat Shrinkage Testing Equipment 0.125 ~ 70 mm



Product Description:



Food Package Wrapping Heat Shrinkage Testing Equipment is designed based on the ISO 14616 international standard. It is applicable to the precisely quantitative determination of the shrinking force, contracting force and shrinkage ratio for heatshrinkable plastic films during the thermal shrinkage process.





Features:



1.3 groups of distinct or identical specimens can be tested at one operation

2.Shrinkage parameters can be accurately obtained by high precision load cell and displacement transducer

3.The system displays the real-time value of shrinking force, contracting force and shrinkage ratio

4.Intelligent reminder for sensor calibration guarantees a safe test environment

5.Viewing and printing of historical data are available in this instrument





  • Shrinking Force and Contracting Force
    Test the shrinking or contracting force of heat-shrinkable films at specified test conditions
  • Shrinkage Ratio
    Test the shrinkage ratio of heat-shrinkable films at specified test conditions





Specifications:



Specifications YYP-009
Capacity Range 0.2 ~ 30 N (standard)
Customization Available
Accuracy ±0.2%
Displacement Range 0.125 ~ 70 mm
Accuracy ±0.125 mm
Temperature Range Room temperature ~ 210°C
Accuracy ±0.5°C
Number of Specimens 1 ~ 3 groups
Specimen Size 130 mm x 15 mm (Standard)
Gas Supply Dry Air (outside of supply scope)
Port Size Φ6 mm PU Tubing
Instrument Dimension 735 mm (L) x 490 mm (W) x 391 mm (H)
Power Supply 220VAC 50Hz / 120VAC 60Hz
Net Weight 0-100 kg





Standards:

ISO-14616-1997, DIN 53369-1976
