Lcd Display Transformer Winding Resistance Test Set , 10a Electrical Test Equipment

China Lcd Display Transformer Winding Resistance Test Set , 10a Electrical Test Equipment supplier
Lcd Display Transformer Winding Resistance Test Set , 10a Electrical Test Equipment supplier Lcd Display Transformer Winding Resistance Test Set , 10a Electrical Test Equipment supplier Lcd Display Transformer Winding Resistance Test Set , 10a Electrical Test Equipment supplier

Large Image :  Lcd Display Transformer Winding Resistance Test Set , 10a Electrical Test Equipment

Product Details:

Place of Origin: China
Brand Name: YUYANG
Certification: ISO
Model Number: WRT-10

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood case
Delivery Time: 15 days
Supply Ability: 100 sets per month
Contact Now
Detailed Product Description
Keyword: Transformer DC Winding Resistance Tester Power Supply: AC220V±10%, 50Hz/60Hz
Display: LCD Measuring Current: 10A
Test Object: Transformer Warranty: 1 Year
Condition: New Color: White

Transformer DC Winding Coil Resistance Tester Set





I. Introduction:

There are four DC currents to select for WRT-10A which has a large output power,the power of transformer DC winding coil resistance tester is very little. Used four lines.It is quick,stable,high precision for testing the winding resistance.

In addition, this winding coil resistance  tester set has a strong ability for anti-jamming ,over current ,over voltage and discharge.the security is also very high, So it is a ideal tester for testing various resistances especially the sensibility equipment.



II. Functions:

  • A new switching power supply technology makes output current more stable and power larger than before.
  • This winding coil resistance tester has an advanced signal process circuit which has a good performance at anti-noise. Test data is precise and stable.
  • The dc winding resistance tester has protections to prevent circuit over-current, circuit over-voltage, wrong operation, discharge and so on.
  • This micro ohmmeter is small size, light weight and more suitable for outdoor using.
  • Varies levels of output current make measuring range more wide.
  • Large-screen LCD makes operation easy.



III.Specifications

1 Resistance precision ±(0.2%RGD+2d)
2 Test range 1.000Ω -1000Ω (20mA)
100.0mΩ -100.0Ω (200mA)
10.00mΩ -20.00Ω (1A)
4.000mΩ -8.000Ω (2.5A)
2.000mΩ -4.000Ω (5A)
1.000mΩ -2.000Ω (10A)
3 The least scale 1uΩ
4 Output current precision ±5%
5 RS232 Support for data uploading to PC
6 Data storage Two hundred groups of data can be stored
7 Build-in thermal printer Print out the result
8 Power supply AC220V±10%,(50±1)HZ
9 Weight 10kg
10 Working condition -10~50℃ Humidity <90% No condensation.



Photos of WRT-5A Transformer DC Winding Coil Resistance Tester

Lcd Display Transformer Winding Resistance Test Set , 10a Electrical Test Equipment
