ASTM D323 Oil Analysis Equipment , Gasoline And Crude Oil Vapour Pressure Test Equipment

China ASTM D323 Oil Analysis Equipment , Gasoline And Crude Oil Vapour Pressure Test Equipment supplier
ASTM D323 Oil Analysis Equipment , Gasoline And Crude Oil Vapour Pressure Test Equipment supplier ASTM D323 Oil Analysis Equipment , Gasoline And Crude Oil Vapour Pressure Test Equipment supplier

Large Image :  ASTM D323 Oil Analysis Equipment , Gasoline And Crude Oil Vapour Pressure Test Equipment

Product Details:

Place of Origin: CHINA
Brand Name: YUYANG
Certification: ISO
Model Number: VPT-R4

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood case
Delivery Time: 20 days
Supply Ability: 100 Sets per month
Contact Now
Detailed Product Description
Test Standard: GB/T8017 ASTM D323 ISO3007 NFM07007 Power Supply: AC220V±5%,50Hz
Temperature Controlling Accuracy: 37.8±0.1℃ Temperature Controlling Method: Imported PID Digital Temperature Controller
Working Units: Two Oxygen Bombs Test Method: Reid Method
Keyword: Vapour Pressure Test Equipment Warranty: 1 Year

ASTM D323 Gasoline and Crude Oil Vapour Pressure Test Equipment

Summary

This instrument is mainly used to determine vapour pressure of gasoline, volatile crude oil and other volatile petroleum products. It can not be used to determine the vapor pressure of LGP.

Filling cooled oil sample into gasoline chamber,and connect with air under certain temperature.


I. Main technical features

1.Micro-computer controller,PID function,digitally display temperature(continuously display during test),accuracy 0.1℃,Pt100 temperature sensor.

2.It’s made by cold-rolled sheet,surface treated by Electrostatic spraying.It’s corrosion resisting and easy to clean.

3.It adopts butt welding technology,so there isn’t welding spot on the surface.It’s beautiful and clean.

4.It adopts imported pressure transmitter,with high accuracy of pressure displaying

5.Complete stainless steel inner water tank can prevent rust very well.

6.Imported quick connector is convenient and sealed tightly.


II. Main technical specifications
1

Applicable standards

GB/T8017 ASTM D323 ISO3007 NFM07007

2

Temperature controlling method

imported PID digital temperature controller
3

Temperature controlling accuracy

37.8±0.1℃

4

Oscillating mode

horizontal automatic,no need manual operation

5

Working units

two oxygen bombs

6

Pressure correction

precise pressure adjust device is connected externally,and micro-adjusting function is set inside.

7

Connection mode

imported stainless steel quick connector makes no leakage

8

Power consumption

1.5KW



ASTM D323 Oil Analysis Equipment , Gasoline And Crude Oil Vapour Pressure Test Equipment
