Blackbody Portable Temperature Calibration Equipment Infrared Thermometer

China Blackbody Portable Temperature Calibration Equipment Infrared Thermometer supplier

Large Image :  Blackbody Portable Temperature Calibration Equipment Infrared Thermometer

Product Details:

Place of Origin: CHINA
Brand Name: YUYANG
Model Number: YYD03

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: Wooden Box
Delivery Time: 1-3 WORK DAYS
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 SETS A MONTH
Contact Now
Detailed Product Description
Power: 220V AC 50HZ Measure Range: 30~50C
Cavity Diameter:: 56mm Application:: Infrared Thermometer
Emissivity: ≥0.99 Function: Temperature Calibrator

New Style Infrared Thermometer Calibration Instrument Blackbody Furnace



1. Product Description

A precision blackbody (black body) is a controlled source of thermal radiation used to calibrate infrared radiation thermometers (pyrometers), thermal imagers and radiation heat flux gauges and radiometers. It is our ZONHOW R&D and manufactured product which is special used in calibration for Infrared ear temperature gun, forehead temperature gun and medical thermometer. It can also be used for the calibration of infrared body surface screening instrument. Through our main R&D of the temperature cycle system, plus the new materials, the emissivity can reach more than 0.99.





2. Product advantages

1) New appearance design, touch screen operation, simple operation.

2) Cree ’s isothermal blackbody cavity has only one cavity mouth. The cavity mouth radiation is evenly distributed with the spectrum, and the cavity mouth emissivity is above 0.99.

4) The automatic heating and temperature control method is adopted, which is safe and reliable, the heating speed is fast, and the temperature stability is good.

5) Convenient operation, small size, light weight, and easy to carry, not only suitable for laboratory calibration, but also for on-site calibration work.

6) Using new technology such as double-row digital display of measured value and set value parameter setting, high precision, high function, and strong anti-interference ability.



4. Specifications

Item Black Body Furnace for Calibration of Infrared Thermometer
Measure Range 30~50ºC adjustable
Temp Resolution 0.01ºC
Cavity Diameter Φ56mm
Cavity Depth 50mm
Emissivity ≥0.99
Temp Stability ±0.1ºC/30min
Temp Uniformity ±0.1C°
Power 220V AC 50HZ
Weight Approx 3.0Kg



5. Features:

1) Emissivity: more than 0.99, isothermal black body cavity, only one cavity mouth, cavity mouth radiation evenly distributed with the spectrum.

2) Novel design, simple operation

3) Adapt automatic temperature control method, safe and reliable, fast temperature rise and good temperature stability.

4) Easy to operate, Small size and light weight, easy to carry. Suitable not only for laboratory calibration, but also for field calibration.

5) Display the measured value, set value and parameter setting with double row digits. New technology, high precision, multi - function and strong anti - interference ability.

Blackbody Portable Temperature Calibration Equipment Infrared ThermometerBlackbody Portable Temperature Calibration Equipment Infrared Thermometer
