ASTM D2419 Fine Sand Equivalent Test Apparatus / Sand Equivalent Test Set

China ASTM D2419 Fine Sand Equivalent Test Apparatus / Sand Equivalent Test Set supplier
ASTM D2419 Fine Sand Equivalent Test Apparatus / Sand Equivalent Test Set supplier ASTM D2419 Fine Sand Equivalent Test Apparatus / Sand Equivalent Test Set supplier ASTM D2419 Fine Sand Equivalent Test Apparatus / Sand Equivalent Test Set supplier

Large Image :  ASTM D2419 Fine Sand Equivalent Test Apparatus / Sand Equivalent Test Set

Product Details:

Place of Origin: CHINA
Brand Name: YUYANG
Certification: ISO
Model Number: FASE

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD10 per set
Packaging Details: plywood case
Delivery Time: 15 days
Supply Ability: 100 sets per month
Contact Now
Detailed Product Description
Keyword: Sand Equivalent Tester Test Standard: ASTM D2419
Oscillating Cycle: (180±2) Times/min Size: 564mm×320mm×360mm
Warranty: 1 Year Power Supply: AC(220±10%)V,50Hz
High Light:

asphalt laboratory equipment

,

bitumen testing instruments

ASTM D2419 Asphalt Test Apparatus Fine Aggregate Sand Equivalent Instrument



Summary
This sand equivalent test instrument is designed and made as per T 0334 Sand Equivalent Test for Fine Aggregate in JTJ 058-2000 Specification and Test Methods of Aggregate for Highway Engineering. It is used to determine the cohesive soil content or impurity content in fine aggregates. The sand equivalent is expressed by SE. The maximum particle diameter shall be less than 4.75mm (The diameter of the sieve is 5mm)

I. Main technical features
1. Double-barrelled design. It can do the parallel oscillation automatically for two samples at a time. The working efficiency is high.
2. Desktop structure. The oscillating frequency and time are both displayed on a LED screen. It can complete a periodic oscillation after sample is loaded.

II.Specifications:
1 Oscillating cycle (180±2) times/min
2 Amplitude of cylinder 203mm±1.0mm
3 Power supply AC(220±10%)V,50Hz
4 Rated power 130 W
5 Dimension of test cylinder Inner diameter is 32mm±0.25mm. Length is 420mm
6 Flushing pipe OD is 6mm±0.5 mm, ID is 4mm±0.2mm
7 Ambient temperature ≤35℃
8 Relative humidity ≤85%
9 Net weight 20kg
10 Dimension 564mm×320mm×360mm
11 Weight of piston 1kg±5g



III.Accessories

No. Item Unit Qty
1 Spare belt(Bonding after burn at both ends to soften by user self) Piece 1
2 Flushing pipe assembly

Water absorbing skin cavity and

flushing pipe

Set 1
Latex tube (Ф7, about 1 meter) Piece 2
Infusion tube spring clips Piece 1
3 Power line (250V 6A) Piece 1
4 2A fuse (Ф5 × 20) Piece 3
5 Funnel Piece 1
6 Test tube (With a rubber stopper) Set 4
7 Counterweight piston Set 1
8 Steel ruler (500mm, precision 1mm) Piece 1
9 Siphon pipe bending Piece 1
10 Mercury thermometer (0 ~ 50 ℃, scale division is1 ℃) Piece 1



ASTM D2419 Fine Sand Equivalent Test Apparatus / Sand Equivalent Test SetASTM D2419 Fine Sand Equivalent Test Apparatus / Sand Equivalent Test Set
