| Place of Origin: | China |
| Brand Name: | YUYANG |
| Certification: | CE, UL, ISO |
| Model Number: | Yjh48 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $10,890.00 - $19770.00/ Set |
| Packaging Details: | Plywood Case |
| Delivery Time: | 15-20 work days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 2 sets per month |
| Product Name: | Walk-in Environmental Test Chamber | Humidity Range: | 20%-98%RH |
|---|---|---|---|
| Heating Time: | According To Chamber Size | Temperature Range: | -40~150°C -20~150°C |
| Stability Humidity: | ±2%RH | Stability Temperature: | ±0.5 Centigrade |
| External Size(cm):: | 93×155×95 |
Custom Temperature Stability Chamber Temp Humidity Chamber Environmental Test Equipment
Uses:
This Good Quality Temperature Humidity Environmental Chamber can simulate different environment condition.It's appropriate for testing material performance, such as resist heat, resist dry, resist humidity and resist cold. That can define performance of material.
Discription:
1. Temperature fluctuation : ± 0.5 ℃2. Humidity fluctuation : ± 0.5% RH
2. Humidity ± 2.5 % RH
Cooling speed: RT 20 ℃ to - 40 ℃ approx. 50 minutes
Heating up speed : RT 20 ℃ to +150 ℃ in about 35 minutes
1. Inner box material: SUS#304 heat-resistant and cold-resistant stainless steel plate
2. Outer box material: Imported cold tie plate spraying, by the matte stripe treatment
Adopt imported TEMI-300 programmable temperature and humidity controller
1. 10 groups of executable programs (100 segments)
2. The maximum execution time of each segment: 99 hours and 59 minutes
3. All cycles 0-999 times, can be freely selected
4. Part of the cycle 0-99 times, can be freely selected
6. With microcomputer PID automatic algorithm function
7. With power-off function, after power resumption, it can continue to execute the unfinished test
8. Can choose single-segment control or multi-segment program control
9. When executing single-segment control, you can change the execution condition value arbitrarily
10. Screen with backlight time control, can adjust the backlight brightness and darkness
11. Memory type multi-functional control, with each group of refrigeration compressor, solenoid valve, heating HEATER, humidifying HEATER and other fully automatic control output function
12. With standard RS-232 communication interface, can be connected to a computer
| Temp&Humi Fluctuation | ±0.5°C;±2.5%RH | ||||||
| Temp&Hum Departure | ±0.5°C-±2°C;±3%RH(>75%RH); ±5%RH(≤75%RH) | ||||||
| Controller Resolution | ±0.3°C;±2.5%RH | ||||||
| Controller Brand | TaiTong | ||||||
| Material | Inwall | SUS 304# steel plate | |||||
| Housing | SUS 304# steel plate surface fog processed | ||||||
| Heat Insulator | resistance to high temperature, high chlorine acid b vinegar foam insulation materials | ||||||
| Aie Circulation Way | centrifugal fan-broadband type force air circulation | ||||||
| Refrigeration Way | cascade type multiple refrigeration | ||||||
| Refrigerater | fully enclosed piston compressor Taikang France | ||||||
| Refrigerants | R4O4Aor American dupont environmental protection cold media(R23+R404) | ||||||
| Condensing Way | Air-cooling | ||||||
| Heater | nickel chrome heating wire heater | ||||||
