Microcomputer Universal Test Equipment Load Resolution 1/50,000 Tensile Testing Machine
Description:
YUYANG series`tensile strength testers are widely applied to determining elongation,
compression, flexing,tear,peeling,shear force,adhesive force,etc.of finished or semifinished products such as rubber,plastic, footwear, leathers, metal,wire, paqer, timber,etc.
Specification:
|
Model |
YY1308 |
|
|
Capacity (optional) |
100, 200, 500 N; 1, 2, 5, 10, 20 kN |
|
|
Unit (Switchable) |
kgf, gf, Ton, lbf, N, kN, or by user`s definition |
|
|
Load Resolution |
1/50,000 |
|
|
Load Accuracy |
±1% |
|
|
Load Range |
Rangeless (full scales at the same amplification) |
|
|
Stroke (exclude the grips) |
1100 mm |
|
|
Effective width |
410 mm |
|
|
Test Speed |
0.000~999 mm/min |
|
|
Speed Accuracy |
±1% |
|
|
Stroke Resolution |
0.01 mm |
|
|
Sample Rate |
16 times/sec |
|
|
Communication Interface |
RS 232(U58 optional) |
|
|
Display method |
U25 (can display and print test value, maximum force, break value, modulus, force, stress, etc.) |
|
|
Motor |
AC servo motor |
|
|
Dimension (WxDxH) |
Main Unit (Height exclusive of footpad) |
111 × 64 × 233 cm |
|
Weight (approx.) |
Main Unit |
384kg |
|
Power |
1∮, 220V,50/60Hz,15A or specified by us |
|
The accessories such as the different grips, elongation measuring-devices... etc. are
equipped according to the requirements specified in the contract; our sales
representative will also give the proper suggestions to our customer beforehand.
