DONGGUAN YUYANG INSTRUMENT CO.,LTD
China Good Quality Manufacturer of Testing Equipment
 |
| Place of Origin: | China |
| Brand Name: | YUYANG |
| Certification: | QB/T 2918-2007 |
| Model Number: | YY1310 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | plywood case |
| Payment Terms: | Western Union, T/T, L/C,Paypal |
| Supply Ability: | 3pcs /week |
| Load Resolution: | 1/50,000 (U25) | Load Accuracy: | ±0.5% |
|---|---|---|---|
| Communication Interface: | USB | Stroke Resolution: | Stroke：0.00125 Mm / Extensometer：0.025 Mm |
| Test Speed: | 5~500 Mm/min Adjustable | Sample Rate: | 16 Times/sec |
| Product Name: | Tensile Testing Machine | Usage: | Tensile Strength Test |
| High Light: | textile lab equipment,universal tensile machine |
||
Micro-Computer Tensile Strength Tester Test Speed 5~500 mm/min Tensile Testing Machine
Description:
YUYANG series`tensile strength testers are widely applied to determining elongation,
compression, flexing,tear,peeling,shear force,adhesive force,etc.of finished or semifinished
products such as rubber,plastic, footwear, leathers, metal,wire, paqer, timber,etc.
Specification:
|
Model |
YY1310 |
|
Capacity (optional) |
100, 200, 500 N; 1, 2, 5 kN |
|
Unit (Switchable) |
kgf, gf, Ton, lbf, N, kN or by user`s definition |
|
Load Resolution |
1/50,000 (U25) |
|
Load Accuracy |
±0.5% |
|
Stroke (exclude the grips) |
1000 mm |
|
Method of Speed Input |
knob |
|
Test Speed |
5~500 mm/min adjustable |
|
Stroke Resolution |
stroke:0.00125 mm / extensometer:0.025 mm |
|
Sample Rate |
16 times/sec |
|
Indicator |
print able, display elongation vatue, test values, max. value & break values. |
|
Motor |
AC servo motor |
|
Dimension (W×D×H) |
55 × 35× 177 cm |
|
Weight (approx.) |
115 kg (excluding control cabinet and grips) |
|
Power |
1∮, 220V, 5A or specified by user 50HZ/60HZ |
The accessories such as the different grips, elongation measuring-devices... etc. are
equipped according to the requirements specified in the contract; our sales
representative will also give the proper suggestions to our customer beforehand.
Contact Person: Mele Pu
Tel: +8618476767313
