Wire And Cable Halogen PH & Conductivity Testing Equipment IEC 60754 Part 1 & 2

Wire And Cable Halogen PH & Conductivity Testing Equipment IEC 60754 Part 1 & 2

  • Wire And Cable Halogen PH & Conductivity Testing Equipment IEC 60754 Part 1 & 2
  • Wire And Cable Halogen PH & Conductivity Testing Equipment IEC 60754 Part 1 & 2
  • Wire And Cable Halogen PH & Conductivity Testing Equipment IEC 60754 Part 1 & 2
  • Wire And Cable Halogen PH & Conductivity Testing Equipment IEC 60754 Part 1 & 2
  • Wire And Cable Halogen PH & Conductivity Testing Equipment IEC 60754 Part 1 & 2
Wire And Cable Halogen PH & Conductivity Testing Equipment IEC 60754 Part 1 & 2
Product Details:
Place of Origin: CHINA
Brand Name: YUYANG
Certification: ISO
Model Number: CTA-M
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood case
Delivery Time: 30 days
Supply Ability: 5 sets
Contact Now
Detailed Product Description
Test Standard: IEC 60754-1&2: 2011 Application Field: Wire&cable
Control Unit: 430 Mm (W) × 370 Mm (D) × 320 Mm (H) Electrical: 110V AC 60Hz / 230V AC 50Hz, 15A
Ambient Temperature: Operating 10°C To 35°C Warranty: 1 Year
Weight: 76Kg Keyword: Halogen Acid Gas Release Corrosion Testing Equipment
High Light:

cable testing equipment

,

spark testing equipment

Please email to Sandy@yuyangtest.com if you need details.



INTRODUCTION



The International Electrotechnical Commission IEC 60754 Part 1 and Part 2 test is performed to determine the degree of acidity of gases evolved during the combustion of materials taken from electric cables by measuring the pH & conductivity.
IEC 60754-1 is halogen-free cable came from and including the polymer to halogenated compounds on the basis of the additive compounds emitted during combustion, except the fluoridation hydracids, it is measure for gas of halogen volume, IEC 60754-2 for electrical or optical cable from compounds emitted during the combustion of measure the gas of oxidation limit.​



FEATURE



  • 1200°C Split-Hinge Tube Furnaces for horizontal use.

  • ​Heating element modules for superior radial and linear temperature uniformity and fast heat up and cool down.

  • ​Long-life, energy-efficient elements require little or no maintenance.

  • ​Mode conversion switch (Test method of IEC 60754-1&2 could be selected).

  • ​Alarm Temperature Controller: Temp controller to protect overheating of furnace.

  • ​Quartz work tube and sample lading assembly.

  • ​pH and conductivity measuring instruments with digital display and electrodes Stirrer.

  • ​Mass flow meter control the flow rate of air and digital display.

  • ​Activated Charcoal (air filtering): Filter for filtering the supplied air (activated charcoal).

  • Silica Gel (air drying): Device for drying the supplied air.

  • ​100 ceramic sample boats.



Installation requirements

Electrical 110V AC 60Hz / 230V AC 50Hz
Ambient Temperature Operating 10°C to 35°C
Size

Dimensions: 889 mm (W) X 432 mm (D) X 406mm (H)

Control Unit: 430 mm (W) × 370 mm (D) × 320 mm (H)

Weight 76KG
Applicable standard IEC 60754 Part 1 and Part 2



Photo of Halogen,pH & conductivity Test Apparatus

Wire And Cable Halogen PH & Conductivity Testing Equipment IEC 60754 Part 1 & 2 0
