| Place of Origin: | China |
| Brand Name: | YUYANG |
| Certification: | CE |
| Model Number: | YY620 |
| Minimum Order Quantity: | 1PCS |
|---|---|
| Price: | $7000 |
| Packaging Details: | Wooden Box |
| Delivery Time: | 7-30 Days |
| Payment Terms: | T/T |
| Product Name: | Sulfur Dioxide Test Machine | Temperature Range: | RT+10℃~50℃ |
|---|---|---|---|
| Humidity Range: | 85~95%RH | Total Power: | Approx.2.5KW |
| Power Supply: | AC380V±10% 50±0.5Hz (three-phase Five Wire System) | ||
| High Light: | Sulfur Dioxide Environmental Test Chamber,2.5KW Environmental Test Chamber,95%RH temperature and humidity chamber |
||
Application:
Sulfur Dioxide Test Chamber can be used to test anti-corrosion ability of a material and its coating layer, and make manufacturing quality on similar coating layers. It can also test corrosion resistance ability of certain products.
Specifications:
Temperature range:RT＋10℃～50℃
| Product Name | |
|
Prohibition of test specimen |
The test equipment prohibits: Testing or storing inflammable, explosive and volatile test specimen. Testing or storing corrosive test specimen. Testing or storing biological test specimen. Testing or storing strong electromagnetic emission source test specimen. Testing or storing radioactive test specimen. Testing or storing toxic test specimens. Testing or storing the test specimens that may produce toxic substances during testing or storing process. |
| Principle/Application | Sulfur Dioxide Test Chamber can be used to test anti-corrosion ability of a material and its coating layer, and make manufacturing quality on similar coating layers. It can also test corrosion resistance ability of certain products. |
| 1. Technical indexes | |
|
Temperature range Humidity range |
RT＋10℃～50℃ 85～95%RH |
|
Temperature uniformity Temperature volatility |
≤2℃ (empty load) ±0.5℃ (empty load) |
|
Gas generation method Concentration of sulfur oxide gas |
Cylinder method 0.1～1.0% (volume percentage) |
|
Total power Power supply |
Approx.2.5KW AC380V±10% 50±0.5Hz (three-phase five wire system) |
