Product Details:
Place of Origin: China
Brand Name: YUYANG
Certification: CE
Model Number: YY056
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: $3050
Delivery Time: 7-30 Days
Payment Terms: T/T
Contact Now
Detailed Product Description
Material: Stainless Steel Machine Lenght: 1600mm
Speed Of Transmission: 18-40 Meter/minute Height Of Inspection Window(cm): 10
Width Of Inspection Window(cm): 40 Detecting Width: 40-120CM
Highest Sensitivity: Ferrous 0.5mm Diameter Ball Non-ferrous: 1.0mm Diameter Ball
High Light:

18m/min Textile Testing Equipment

,

120CM Textile Testing Equipment

,

40m/min Metal Inspection Equipment

Metal Inspection Equipment Auto-Conveyor Metal Needle Detector for Cloth/Food 0

Application:

Transmission type all-digital metal detection machine is a new generation of microcomputer intelligent metal detection equipment launched by the company. The product has high sensitivity and stable performance. Besides, it breaks through the technical bottleneck that most of the equipment only responds sensitively to magnetic substances, and has a good elimination performance for products with moisture and frozen products.The device can detect metals such as iron and non-iron, and can be widely used for metal detection in demanding objects such as food, medicine and toys.



Use:

It was mainly used for: sauces, sausages, dumplings, ham, soup, sugar products, pickled foods, salted foods, fast food and other non-food industries, the high detection sensitivity, anti-interference ability and waterproof standard for hard-working condition, to detect the mixed or lost needle, wire, or lead, copper, aluminium, tin, stainless steel and other kinds of metal in food, raw materials or products





Feature:

1. Double circuit electromagnetic wave detection, new analog circuit and digital circuit combination, improve the sensitivity and reliability of detection.

2. The new type of touch screen input and composition of large scale integrated circuit improve the intelligence of detection (LIQUID crystal type).

3. User-friendly interface design, multi-language operation, the whole process is simple and intuitive, human-machine interface at a glance (LIQUID crystal).

4. Dynamic zero point voltage tracking, automatic learning detection function, reduce personnel operation.

5. Wide adjustable range of sensitivity, with reverse detection function (no alarm for metal products, no alarm for metal products).

6. When metal is detected, sound, light and alarm will be given at the same time, and the machine will stop or kick out the unqualified products (optional functions).





Parameter:

Detected Height(mm)
80
100
150
200
250
300
350
Belt Width(mm)
250
250
400
400
400
400
400
Belt length
1500
Detector sensitivity(mm)
Fe 0.8
Fe 1.0
Fe 1.2
Fe 1.5
Fe 2.0
Fe 2.5
Fe 3.0
SUS 1.0
SUS2.0
SUS2.5
SUS2.5
SUS3.0
SUS3.5
SUS4.0
N-Fe 1.0
N-Fe1.5
N-Fe2.0
N-Fe2.0
N-Fe2.5
N-Fe3.0
N-Fe3.5
Speed of belt
25M/min (Fixed speed) ;
If you need adjust 5-40 M/min , please inform us before order
Load ability
20KG
Count
100
Warning method
ound and light alarm ; The belt can be stopped, continue run or belt return ( the option you can selected in PLC controller)
Reject Ways
when has auto-reject system ,belt continue and rejecting the goods
Application
Non-package ,plastic package ,paper bag or box (non-metallic) product
Work Environment
Temperature -10℃-40℃ ,relative humility 30-90%
