Product Details:
Place of Origin: China
Brand Name: YUYANG
Model Number: YY030
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: $1000
Packaging Details: Wooden Box
Delivery Time: 7-30 Days
Payment Terms: T/T, Western Union, MoneyGram
Contact Now
Detailed Product Description
Product Name: Fabrics Induction Type Electrostatic Tester Usage: Electrostatic Induction Fabric Test
Voltage Range: 0 ~ 10KV Rotary Speed: 1500r / Min
Sample Size: 45*45mm Power Supply: AC220V 50Hz 60W
Weight: 85Kg Dimensions: 720 * 560 * 1400mm
High Light:

Electrostatic Textile Testing Equipment

,

1500r/Min Textile Testing Equipment

,

Fabrics Induction electrostatic tester

Fabrics Induction Type Electrostatic Tester Detector Machine



Description:



Fabrics Induction type Electrostatic Tester .With the Laboratory conditions, it can determine the electro-static properties of various textile raw materials and made-up goods (including fiber, yarn, fabrics,carpet, decoration fabrics). It can also be used to measure the electro-static performances to other sheets (plates) such as paper, rubber, plastic, composite sheets and so on.



Specifications:



Measuring Range of Electro-static Voltage: 0 ~ 10KV

Half-life Time Limit Range: 0 ~ 10000s,error±1s

Sample Tray Rotating Speed: >1000r/min

Discharge Time: 0 ~ 99s to be adjustable(

standard requirement:30s±0.1s)

Discharge Distance between Pin Electrode and Testing Specimen: 20mm

Measuring Space between Testing Sensing Probe and Testing Specimen: 15mm

Test Specimen Size: 60mm×80mm ( 3pcs )

Power Source: 220V 50HZ 300W

Applicable standards: GB/T12703;FZ/T010426
