Electronic Double Wing Box Drop ISTA Packaging Testing For Carton Box Drop Testing
Product Details:
Place of Origin: China
Brand Name: YUYANG
Certification: ISTA 1A, ASTM D999
Model Number: YY038
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Plywood Case
Delivery Time: 15-20 work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 2 sets per month
Contact Now
Detailed Product Description
Dropping Height: 300mm-1500mm Display Method: Digital Display
Maximum Weight Of The Package: 60KG Maximum Size Of The Package(L×W×H): 1000×700×1000mm
Size Of The Dropping Panel(L×W): 1700×1400mm Size Of The Swing: 200×150×8mm
Test Space: 1000×1000mm (can Customize) Dropping Deviation: 10mm
Weight: 550KG Power: AC380V,50Hz
High Light:

AC380V Carton Box Drop Tester

,

Digital Display Package Drop Test Machine

,

GB/T4857.5 Package Drop Test Machine

Electronic Double Wing Box Drop ISTA Packaging Testing For Carton Box drop Testing



Description:

During the products handling or transport process, there may be drop/ fall, which results in damage within the products. And ISO 2248 Digital Carton Impact Testing Equipment simulates the drop/ fall of a finished product to evaluate the damage. All the rhombohedrons, angles and faces of the products can be tested.



Function:

Electronic Drop Tester Exporter is used to test the damage degree when the package is dropped, and test the impact resistance of the package during transportation, for example, to test the surface, edge and angle of the package through free-drop method.



Technical parameters:

1. Dropping height: 300mm-1500mm

2. Display method: digital display

3. Maximum weight of the package: 60kg

4. Maximum size of the package: (L×W×H)1000×700×1000mm

5. Size of the dropping panel: (L×W)1700×1400mm

6. Size of the swing: 200×150×8mm

7. Dropping deviation: 10mm

8. Deviation of dropping horizon: less than 1°

9. Outside size: (L×W×H)1700×1200×2500mm

10. Chamber size: (L×W×H)350×350×1100mm

11. Weight: 550kg

12. Power: AC380V,50Hz



Standards: GB/T4857.5, ISO 2248,JIS Z0202,ASTM D5276



Configuration:

1. Outside material: advanced paint coat

2. Display: LCD display

3. Power system:drive device(imported motor + speed reducer +Axel+ upper and lower limitation + spring +electromagnet)+ dropping device(dropping standard board +magnet + safety spacing push rod + automatic return back + digital alto-meter +encoder + hydraulic pressure buffering device)

4. Control system: adopting electromagnet sensor control, the interface is easy to operate, high degree automatic control

5. Safety device:upper and lower limitation device, automatic off-power device if electricity leakage occurs

6. Accessories:electric wire 1 piece, guarantee certificate 1 piece, operational manual 1 piece

Dropping height 300mm-1500mm
Display method Digital display
Maximum weight of the package 60kg
Maximum size of the package(L×W×H) 1000×700×1000mm
Size of the dropping panel(L×W) 1700×1400mm
Size of the swing 200×150×8mm
Dropping deviation 10mm
Weight 550kg
Power AC380V,50Hz
