110V / 220V AC Vertical Profile Projector Rotation 360 Optical Measuring

110V / 220V AC Vertical Profile Projector Rotation 360 Optical Measuring

  • 110V / 220V AC Vertical Profile Projector Rotation 360 Optical Measuring
  • 110V / 220V AC Vertical Profile Projector Rotation 360 Optical Measuring
  • 110V / 220V AC Vertical Profile Projector Rotation 360 Optical Measuring
  • 110V / 220V AC Vertical Profile Projector Rotation 360 Optical Measuring
  • 110V / 220V AC Vertical Profile Projector Rotation 360 Optical Measuring
110V / 220V AC Vertical Profile Projector Rotation 360 Optical Measuring
Product Details:
Place of Origin: China
Brand Name: YUYANG
Certification: ISTA 1A, ASTM D999
Model Number: YY048
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $10
Packaging Details: Plywood Case
Delivery Time: 15-20 work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 2 sets per month
Contact Now
Detailed Product Description
Illumination: The Illumination Of Transmission And Reflection: 24V/150W-halogen Lamp Power: 110V/220V(AC), 50/60HZ, Total Power=400W
Cold: Forced Air Cooling Dimensions: 770*810*1120mm
Weight: 170kg Max Work Piece Height: 90mm 90mm 90mm 90mm
Working Distance (mm): 77.7 44.3 38.4 25.3 Object View (mm): Ø30 Ø15 Ø6 Ø3
Magnification: 10X Option 20X Option 50X Option 100X Option
High Light:

220V Vertical Profile Projector

,

Rotation 360 Vertical Profile Projector

,

Optical Vertical Profile Projector

110V/220V(AC) Rotation 360 Optical Measuring Vertical Profile Projector



Description:

1. Vertical profile projector is mainly used for the measurement of the mechanical parts of the length, angle, contour and surface shape.

2. Rotation 360 optical measuring vertical profile projector can inspect all kinds of surface and outline of complicated work-Pieces, cam, screw thread, gear, perform milling cutter and so on.

3. Optical measuring vertical profile projector widely used in the trade of mechanism, meter, electricity, light industry, college, research institute and measurement-inspecting department.

4. Measurement data can output and connect printer and computer.



Product Features:

• Top quality profile projector highly versatile and easy to operate;

• Large travel range 200mm x 100mm as standard;

• Linear scale stage with 0.0005mm resolution;

• Fine ground glass screen for clear image;

• Built-in profile and surface illumination;

• 10x, 20x, 50x, 100x projection lenses available.



Model YY047









Table

The metal table’s size 450 x280 mm
The glass table’s size 306x196mm
X-axis travel 200mm
Y-axis travel 100mm
Z-axis travel 90 (for focus)
Measuring accuracy 3+L/200 um
Resolution (X-axis, Y-axis): 0.001 mm
Projector screen Screen size (mm): Ø 312 Used range>Ø 300(with the meter line)
Screen rotary range: 0°~360°
Resolution (X-axis, Y-axis): 1´ or 0.01°



Lens

Magnification: 10X option 20X option 50X option 100X option
Object view (mm): Ø30 Ø15 Ø6 Ø3
Working distance (mm): 77.7 44.3 38.4 25.3
Max. work piece height: 90mm 90mm 90mm 90mm
Data Processing System DP-100multi-function data processing system, appearing in English, can be used to gather the data and measure the point, line, circle, angle and distance.
Illumination The illumination of transmission and reflection: 24V/150W-halogen lamp.
Power 110V/220V(AC), 50/60HZ, Total power=400W
Cold Forced air cooling
Dimensions 770*810*1120mm
Weight 170kg



Specification:





110V / 220V AC Vertical Profile Projector Rotation 360 Optical Measuring 0







1. Screen 2. screen fast move handle 3. DP-400 Digital Readout
4. Rotary fine tune knob 5. projector frame 6. main body of transmission illumination
7. X axis knob 8. lifting knob 9. footing
10. carry knob 11. dust cover 12. Y axis
13. Base 14. Vertical work table 15. hinge group
16. worktable 17. lower stage table 18. reflection illumination
19. objective 20. upper stage table 21. null position
22. lock screw 23. elastic platen



Characteristics:

1) Solid framework, large LCD touch screen and advanced QM2.0 software;

2) High quality optics for crisp and clear images;

3) Adjustable LED surface and contour illumination;

4) High resolution industrial CCD camera;

5) 6.5X Detente zoom lens changeable within the range of 30-190x magnification;

6) Easy to operate user interface;

7) Extended function of printing, saving and exporting data;

8) Excel, word or txt multi-format report output, and DXF input and output;

9) Non-contact optical height measurement;

10) Automatic edge-detecting function;

11) Make Save and input the program;

12) Map photo and measurement;

13) Dimension label function;
