Place of Origin: | China |
Brand Name: | YUYANG |
Certification: | ISO2403 BS3181 ASTMD1448; ISO1136 BS3183 ASTMD1282A |
Model Number: | YY076 |
Minimum Order Quantity: | 1 set |
---|---|
Price: | $10 |
Packaging Details: | Plywood Box |
Delivery Time: | 5-10 work days |
Payment Terms: | T/T, L/C, Western Union |
Supply Ability: | 100 sets per month |
Force Scale: | 0-1000cN; 0-3000cN; 0-5000cN | Force Division: | 0.5CN; 1CN; 1cN |
---|---|---|---|
Precision: | <=1 %F.S | Extension Speed: | 50-1000mm/min (adjustable) |
Reverting Speed: | 50-1000mm/min (adjustable) | Extension Scale: | 100mm,250mm,500mm (three Selection) |
Pretension: | 0~150cN (adjustable) | Power: | AC 220V±10% 50Hz |
Dimension: | 370*450*970mm | Weight: | 60kg |
High Light: | 220V Single Yarn Strength Tester,Electronic Single Yarn Strength Tester,ASTM D2256 Single Yarn Strength Tester |
Single Yarn Strength Tester For Determining The Breaking Load And Extension
Description:
Electronic Single Yarn Strength Tester is suitable for determining the breaking load and extension of single yarns. It does adopt CRE principle and automatically operated with pneumatic/magnetic clamp, provided with scales 0-5000cN force max.
Standards: GB/T14344, GB/T3916, ISO2062, ASTM D2256
Parameters:
Force scale:0-1000cN; 0-3000cN; 0-5000cN
Force division: 0.5CN; 1CN; 1cN
Precision:<=1 %F.S
Extension speed:50-1000mm/min (adjustable)
Reverting speed:50-1000mm/min (adjustable)
Extension scale:100mm,250mm,500mm (three selection)
Pretension: 0~150cN (adjustable)
Power:AC 220V±10% 50Hz
Dimension: 370*450*970mm
Weight:60kg
Force scale | 0-1000cN; 0-3000cN; 0-5000cN |
Force division | 0.5CN; 1CN; 1cN |
Precision | <=1 %F.S |
Extension speed | 50-1000mm/min (adjustable) |
Reverting speed | 50-1000mm/min (adjustable) |
Extension scale | 100mm,250mm,500mm (three selection) |
Pretension | 0~150cN (adjustable) |
Power | AC 220V±10% 50Hz |
Dimension | 370*450*970mm |
Weight | 60kg |
