YUYANG Fabric Tearing Strength Tester 510×400×565mm Multipurpose

YUYANG Fabric Tearing Strength Tester 510×400×565mm Multipurpose

  • YUYANG Fabric Tearing Strength Tester 510×400×565mm Multipurpose
  • YUYANG Fabric Tearing Strength Tester 510×400×565mm Multipurpose
  • YUYANG Fabric Tearing Strength Tester 510×400×565mm Multipurpose
  • YUYANG Fabric Tearing Strength Tester 510×400×565mm Multipurpose
YUYANG Fabric Tearing Strength Tester 510×400×565mm Multipurpose
Product Details:
Place of Origin: CHINA
Brand Name: YUYANG
Certification: CE
Model Number: YYP0010C
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Wooden Box
Delivery Time: 7-30 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5 Pcs Per Month
Contact Now
Detailed Product Description
Product Name: Tear Resistant Paper Package Tester Dimension: 510×400×565mm
Temperature: (20±10)℃, Humidity<85% Working Environment: Temperature:(0~35)℃, Humidity<85%
Distance Between Clip Board Devices: 2.8±0.3mm Specimen Size: 50×63mm
Clip Board Size: 25×15mm Power Supply: AC 220V 50Hz Or Specified By User
High Light:

50Hz Tearing Strength Tester

,

Elmendorf Tearing Strength Tester

,

220V Fabric Tearing Strength Tester

Tear Resistant Paper Package Testing Equipment GBT 455 High Temperature

YUYANG Fabric Tearing Strength Tester 510×400×565mm Multipurpose

Description:



Tearing resistance tester is used for testing tearing resistance of paper and paper board, it is also used for testing tearing resistance of flaky composite materials like textile, leather and thin film.





Features:



(1) Compact structure design to ensure the elegant appearance, also easy to maintain

(2) The configuration is very flexible, to reach different functions

(3) Precision production, to ensure the high accuracy







Product application:



The tester can be applied in testing paper tearing strength. If change the configuration, it can be used to test other materials, like plastic, chemical fiber, metal wire, metal foil and so on.



Technical standards:



ISO 1974:1990 <Paper -- Determination of tearing resistance (Elmendorf method)>

GB/T 10739-2002 <Paper, board and pulps – Standard atmosphere for conditioning and testing>

ISO 186:1994 <Paper and board - Sampling to determine average quality>

GB 455.1 <Paper - Determination of tearing>



Model YY1402
Measuring range Stage A: (50-8000)mN, Stage B: (8000-16000)mN
Tearing arm of force 104±1mm
Tearing initial angle 27.5±0.5°
Tearing distance 43±0.5mm
Clip board size 25×15mm
Specimen size 50×63mm
Distance between clip board devices 2.8±0.3mm
Working environment temperature:(0~35)℃, humidity<85%





YUYANG Fabric Tearing Strength Tester 510×400×565mm Multipurpose 0YUYANG Fabric Tearing Strength Tester 510×400×565mm Multipurpose 1
