50kN 100kN 200kN UTM Universal Tensile Testing Machine Mechanical Materials Cable Tensile Test Equipment

50kN 100kN 200kN UTM Universal Tensile Testing Machine Mechanical Materials Cable Tensile Test Equipment

200kN UTM Universal Tensile Testing Machine

100kN UTM Universal Tensile Testing Machine

50kN UTM Universal Tensile Testing Machine

Place of Origin:

China

Brand Name:

YUYANG

Certification:

QB/T 2918-2007

Model Number:

YY1308

Contact Us
Request A Quote
50kN 100kN 200kN UTM Universal Tensile Testing Machine Mechanical Materials Cable Tensile Test Equipment
50kN 100kN 200kN UTM Universal Tensile Testing Machine Mechanical Materials Cable Tensile Test Equipment 50kN 100kN 200kN UTM Universal Tensile Testing Machine Mechanical Materials Cable Tensile Test Equipment 50kN 100kN 200kN UTM Universal Tensile Testing Machine Mechanical Materials Cable Tensile Test Equipment 50kN 100kN 200kN UTM Universal Tensile Testing Machine Mechanical Materials Cable Tensile Test Equipment 50kN 100kN 200kN UTM Universal Tensile Testing Machine Mechanical Materials Cable Tensile Test Equipment
Product Details
Unit (Switchable):
100, 200, 500 N; 1, 2, 5, 10, 20，30 KN
Motor:
AC Servo Motor
Communication Interface:
Textile Testing Equipment
Stroke Resolution:
0.01 Mm
Test Speed:
0.000~999 Mm/min
Sample Rate:
16 Times/sec
Product Name:
Tensile Testing Machine
Load Resolution:
1/50,000
Highlight:

200kN UTM Universal Tensile Testing Machine

,

100kN UTM Universal Tensile Testing Machine

,

50kN UTM Universal Tensile Testing Machine

Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
Negotiation
Packaging Details
plywood case
Payment Terms
Western Union, T/T, L/C,Paypal
Supply Ability
3pcs /week
RELATED PRODUCTS
Good price Computer Control Tensile Strength Test Machine For Yarn / Textile / Plastic online

Computer Control Tensile Strength Test Machine For Yarn / Textile / Plastic

Get Best Price
Good price YYL-006 Mechanical Equipment Automatic Electronic Tensile 100kn 50kn Hydraulic Universal Testing Machine For Geocell Straps online Video

YYL-006 Mechanical Equipment Automatic Electronic Tensile 100kn 50kn Hydraulic Universal Testing Machine For Geocell Straps

Get Best Price
Good price AC220V YYL-001 10kn 20kn 50kn 100kn 200kn 300kn Universal Tensile Strength Testing Machine For Terminal Tensile Testing online Video

AC220V YYL-001 10kn 20kn 50kn 100kn 200kn 300kn Universal Tensile Strength Testing Machine For Terminal Tensile Testing

Get Best Price
Good price 600kn Laboratory Rock Bolt Test Instrument For Anchorage Rebar Tensile Testing 10kn 100kn Universal Testing Machine 2ton 5ton 10 Ton Plastic Rubber Steel Ropes Metal Material Utm Tensile Str online Video

600kn Laboratory Rock Bolt Test Instrument For Anchorage Rebar Tensile Testing 10kn 100kn Universal Testing Machine 2ton 5ton 10 Ton Plastic Rubber Steel Ropes Metal Material Utm Tensile Str

Get Best Price
Contact Us
86-769-26622869
Contact Now
Product Description

50kN 100kN 200kN UTM Universal Tensile Testing Machine Mechanical Materials Cable Tensile Test Equipment





Description:



YUYANG series`tensile strength testers are widely applied to determining elongation,

compression, flexing,tear,peeling,shear force,adhesive force,etc.of finished or semifinished products such as rubber,plastic, footwear, leathers, metal,wire, paqer, timber,etc.



Applications

  • Tested sample: laminated materials, wood, leather, rubber & plastic, metal material, etc.
  • Different test with different grips: tensile, peel, tear, heat seal, adhesive, bend and open force.
  • Deformation under defined load: Test deformation under defined load of tested sample
  • Load under defined deformation: Test load under defined deformation of tested sample
  • Software can issue word/excel report with results for max. force, elongation, tensile strength, peel strength, tear strength, compression strength, etc.



Specification:



Model

YY1308

Capacity (optional)

100, 200, 500 N; 1, 2, 5, 10, 20 kN

Unit (Switchable)

kgf, gf, Ton, lbf, N, kN, or by user`s definition

Load Resolution

1/50,000

Load Accuracy

±1%

Load Range

Rangeless (full scales at the same amplification)

Stroke (exclude the grips)

1100 mm

Effective width

410 mm

Test Speed

0.000~999 mm/min

Speed Accuracy

±1%

Stroke Resolution

0.01 mm

Sample Rate

16 times/sec

Communication Interface

RS 232(U58 optional)

Display method

U25 (can display and print test value, maximum force, break value, modulus, force, stress, etc.)

Motor

AC servo motor

Dimension (WxDxH)

Main Unit (Height exclusive of footpad)

111 × 64 × 233 cm

Weight (approx.)

Main Unit

384kg

Power

1∮, 220V,50/60Hz,15A or specified by us





50kN 100kN 200kN UTM Universal Tensile Testing Machine Mechanical Materials Cable Tensile Test Equipment 050kN 100kN 200kN UTM Universal Tensile Testing Machine Mechanical Materials Cable Tensile Test Equipment 150kN 100kN 200kN UTM Universal Tensile Testing Machine Mechanical Materials Cable Tensile Test Equipment 250kN 100kN 200kN UTM Universal Tensile Testing Machine Mechanical Materials Cable Tensile Test Equipment 3

Accessories such as different grips, elongation measuring devices... Etc. are



Equipped according to the requirements stipulated in the contract; Our sales



The representative will also give our clients appropriate advice in advance.

50kN 100kN 200kN UTM Universal Tensile Testing Machine Mechanical Materials Cable Tensile Test Equipment 4
