Name: Touch Screen Environmental Test ChamberSUS 304 Material TEMI Controller
Brand: DONGGUAN YUYANG INSTRUMENT CO., LTD
SKU: YY1026
Price: 11957.00 USD
Availability: InStock

Home > products > Environmental Test Chamber >

Touch Screen Environmental Test ChamberSUS 304 Material TEMI Controller

environmental chamber

custom environmental chambers

environmental control chamber

Place of Origin:

China

Brand Name:

YUYANG

Certification:

CE, UL, ISO, IEC

Model Number:

YY1026

Request A Quote

Touch Screen Environmental Test ChamberSUS 304 Material TEMI Controller

Product Details

Product Name:

Touch Screen Environmental Test ChamberSUS 304 Material TEMI Controller

Usage:

Temperature And Humidity Test Chamber

Temp Analytic Accuracy:

0.10ºC/±2.00ºC

Temperature Fluctuation:

±0.50ºC

Power Supply:

AC220V, 50/60HZ

Humidity Analytic Accuracy:

±0.10%;±2.50%

Heat Up:

4.00°C/min

Cooling:

1.00°C/min

Highlight:

environmental chamber

custom environmental chambers

environmental control chamber

Payment & Shipping Terms

Price

Negotiation

Packaging Details

Plywood Case

Delivery Time

11 work days

Payment Terms

T/T, L/C, Western Union

Supply Ability

4 sets per month

Stainless Steel Customize Built Free Standing Ovens Electric Aluminium Coating

Get Best Price

High Configuration Salt Spray Test Machine X-60 Salt Spray Corrosion Test Equipment

Get Best Price

Programmable Low Temperature Environmental Test Chamber For Temperature Humidity Test Machine

Get Best Price

Lab Weathering Tester Battery Sprinkler Uv Aging Environmental Test Chamber

Get Best Price

86-769-26622869

Contact Now

Product Description

Touch Screen Environmental Test ChamberSUS 304 Material TEMI Controller

Product Description:

Constant Temperature and Humidity test chamber is a precise and durable conditioning system that able to offer quick and constant conditions from 5% to 98% R.H. +/- 0.5% and-70°C to 150°C +/-0.5°C, is widely used for the resistance test to heat, cold, dry, and humidity etc, and used for the conditioning of many kinds of samples prior to testing
Constant Temperature and Humidity test chamber is designed for testing the capability of heat-endurance, cold-endurance, dryness-endurance, and humidity-endurance, suitable for quality control of the industries of electron, electrical equipment, vehicle, metal, foodstuffs, chemistry, building materials, luggage, adhesion tape, printing, packaging, etc.

Comprehensive Warranty and Support: We offer a 1-year warranty and dedicated support to ensure your complete satisfaction with our High Standard Temperature And Humidity Testing Machine.

Specifications:

Model	YY1026-80 (A~F)	YY1026-150 (A~F)	YY1026-225 (A~F)	YY1026-408 (A~F)	YY1026-800 (A~F)	YY1026-1000 (A~F)
Inner size: WHD(cm)	405040	506050	607550	608580	10010080	100100100
External size: WHD(cm)	10516598	105175108	115190108	135200115	155215135	155215155
Humidity range	20%~98% R.H.(10%~98%R.H);(5%~98%R.His special optional condition)
Temp analytic accuracy/ uniformity	0.1ºC/±2.0ºC
Temperature Fluctuation	±0.5ºC
Humidity analytic accuracy/ Humidity control accuracy	±0.1%;±2.5%
Heat; cooling time	Heat up about 4.0°C/min ; Cooling about 1.0°C/min
Inner and outer materials	SUS#304 Stainless steel for inner chamber ; Carton Advanced cold plate nano paint for outer
Insulation materials	Resistant to high temp ,high density,formate chlorine,ethyl acetum foam insulation materials
Protection devices	Fuse switch, compressor overload switch, refrigerant high and low pressure protection switch, super humidity over-temperature protection switch, fuse, failure warning system
Compressor	Original France "Tecumseh" brand
Controller	TEMI South Korea
Power	AC220V 50/60Hz & 1 , AC380V 50/60Hz 3
weight (kg)	150	220	270	320	450	580
