Name: Ultra-High Frequency Induction Heating 100kw LGBT Continuous Induction Heat Automatic Aluminium Foil Sealing Machine For Bottle Mouth
Brand: DONGGUAN YUYANG INSTRUMENT CO., LTD
SKU: YYS - 100AB
Price: 5,500.00 USD
Availability: InStock

Home > Products > Electrical Test Set >

Ultra-High Frequency Induction Heating 100kw LGBT Continuous Induction Heat Automatic Aluminium Foil Sealing Machine For Bottle Mouth

100kw induction heating machine

LGBT continuous induction heat

aluminium foil sealing machine

Place of Origin:

China

Brand Name:

YUYANG

Certification:

CE, ISO

Model Number:

YYS - 100AB

Request A Quote

Product Details

Rated Power Output:

100Kw

Frequency Rang:

10-50khz

Current Input:

150A

Product Size:

Main : 790x695x1060mm; Transformer : 865x420x650mm

Net Weight:

Main : 123kg; Transformer : 84kg

Gross Weight:

50C

Duty Cycle:

100%

Brand:

YUYANG

The Flow Rate Of Cooling Water::

0.08-0.16Mpa 10L/Min

Output Current:

400-4000A

Highlight:

100kw induction heating machine

LGBT continuous induction heat

aluminium foil sealing machine

Payment & Shipping Terms

Minimum Order Quantity

Set/Sets

Price

US $ 5000-6000

Packaging Details

1160 x 1040 x 1320mm

Delivery Time

5-15 days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

100 sets per month

Ultra-High Frequency Induction Heating 160kw LGBT Automatic Portable Induction Brazing Heating Machine

Get Best Price

Video

Ultra-High Frequency Induction Heating 60 kw LGBT Copper And Brass Tube Induction Brazing Welding Machine

Get Best Price

Video

Ultra-High Frequency Induction Heating 100kw LGBT Continuous Induction Heat Automatic Aluminium Foil Sealing Machine For Bottle Mouth

Get Best Price

Video

Ultra-High Frequency Induction Heating 40KW LGBT Gear Shaft Superaudio Frequency Induction Tempering Annealing Quenching

Get Best Price

8613825721469

sales06@yuyangtest.com

86-769-26622869

Contact Now

Product Description

Ultra-High Frequency Induction Heating 100kw LGBT Continuous Induction Heat Automatic Aluminium Foil Sealing Machine For Bottle Mouth

This equipment adopts the IGBT inverter circuit in parallel connection, which has high load adaptability. It features high power, fast heating speed, high efficiency and easy operation.

Industrial Applications

Heating Applications

Hot forging for shaping work pieces using punch press, forging machine
Hot fitting for metal connections and compound materials
Smelting for melting metals into liquid form

Heat Treatment

Designed to change the rigidity of metal materials through heat treatment processes:

Quenching for tools, automotive parts, electric tools, machine tools
Quench for various hardware metal parts and machined parts (shaft, gear, cam, chuck, clamp)
Quench for hardware molds, small-size molds, mold accessories and inner holes
Hardening of mechanical parts, gears, shafts, and mold components

Welding Applications

Braze welding, silver soldering & brazing
Welding of cutting tools, mechanical gadgets, and composite materials
Specialized applications for pot bottom welding and heating elements

Annealing Processes

Annealing of stainless steel products and various metal work pieces
Applications for aluminum products, brass components, and more
Tempering and modulation processes

Front View

Internal Components

Cooling System

Technical Features

• Uses imported high-quality IGBT solid power module with advanced frequency conversion technology
• Advanced cooling system enables 24-hour continuous operation at maximum power
• Constant current and power control function for improved heating efficiency and energy savings
• Simple installation - operates after connecting to 380V power and water connections
• Programmable timing function with adjustable heating time, heat-preservation time, and current settings
• Comprehensive self-diagnosis system with multi-level protection against overvoltage, overcurrent, overheating, and phase loss
