Portable Brazing Welder Small air Conditioning Tube Copper Tube Welding Equipment

Portable Brazing Welder Small air Conditioning Tube Copper Tube Welding Equipment

portable brazing welder for copper tubes

small air conditioning tube welder

copper tube welding equipment with warranty

Place of Origin:

China

Brand Name:

YUYANG

Certification:

CE,CO

Model Number:

YYS-100AB

Contact Us
Request A Quote
Portable Brazing Welder Small air Conditioning Tube Copper Tube Welding Equipment Portable Brazing Welder Small air Conditioning Tube Copper Tube Welding Equipment Portable Brazing Welder Small air Conditioning Tube Copper Tube Welding Equipment Portable Brazing Welder Small air Conditioning Tube Copper Tube Welding Equipment
Product Details
Model:
YYS-100AB (Three Phase)
Work Power:
340V-430V
Maximum Input Current:
150A
Output Power:
100KW
Fluctuating Frequency:
10-50khz
Output Current:
400-4000A
The Flow Rate Of Cooling Water:
0.08-0.16Mpa 10L/Min
Water Temperature Protection Point:
50°C
Product Size:
Main : 790x695x1060mm Transformer : 865x420x650mm
Net Weight:
Main : 123kg Transformer : 84kg
Highlight:

portable brazing welder for copper tubes

,

small air conditioning tube welder

,

copper tube welding equipment with warranty

Payment & Shipping Terms
Minimum Order Quantity
Single item
Price
5739$
Payment Terms
T/T
Supply Ability
1 - 20pieces(15days)
RELATED PRODUCTS
Good price Automatic Plastic Bag Sealer Hot Air Impulse Heat Sealing Machine with Aluminum Frame Pedal Induction Sealing Machine online

Automatic Plastic Bag Sealer Hot Air Impulse Heat Sealing Machine with Aluminum Frame Pedal Induction Sealing Machine

Get Best Price
Good price High Frequency Electromagnetic Induction Heating Generator for Steel Bar in Metal & Metallurgy Machinery online

High Frequency Electromagnetic Induction Heating Generator for Steel Bar in Metal & Metallurgy Machinery

Get Best Price
Good price Electromagnetic Induction Heating Furnace Machine Digital Metal Welding Equipment for Manufacturing Plant for School Use online

Electromagnetic Induction Heating Furnace Machine Digital Metal Welding Equipment for Manufacturing Plant for School Use

Get Best Price
Good price Industrial Grade Induction Heater With Custom Power for 24H Metal Processing Operations Order From One Machine online

Industrial Grade Induction Heater With Custom Power for 24H Metal Processing Operations Order From One Machine

Get Best Price
Contact Us
8618938165008
sales11@yuyangtest.com
86-769-26622869
Contact Now
Product Description
Portable Brazing Welder for Small Air Conditioning & Copper Tube Welding
Portable High-Frequency Induction Heating Machine Series designed for precision welding and heating applications in various industrial settings.
Portable Brazing Welder Small air Conditioning Tube Copper Tube Welding Equipment 0
Available Models
Model Power Rating
YYS40AB 40KW
YYS60AB 60KW
YYS100AB 100KW
Technical Features
  • IGBT inverter circuit in parallel connection for high load adaptability
  • High power output with fast heating speed and operational efficiency
  • Compact design saves production space by 10 times compared to conventional equipment
  • Safe operation without high-voltage equipment requirements
  • 24-hour continuous operation capability with comprehensive full load design
  • Energy efficient operation that reduces material waste and labor intensity
Primary Applications
Heating Applications:
  • Hot Forging: Shaping workpieces at specific temperatures using forging presses for watch cases, handles, mold accessories, kitchenware, mechanical parts, and fasteners
  • Hot Fitting: Connecting different metals or metals with nonmetals using thermal expansion principles for computer radiators, speaker components, steel-plastic tube compounds, and motor rotors
Quality Standards
Manufactured under strict quality controls with relevant certifications. Engineered for internal precision and external durability to ensure long-term reliable performance.
Core Advantages
Efficiency: 30-80kHz frequency enables uniform heating in minutes
Portability: Compact design with customizable coaxial cable length for flexible workspace adaptation
Durability: Imported components ensure zero power loss and extended service life
Versatility: Adaptable to various metals and applications from automotive manufacturing to machinery repair
This induction heating series represents the forefront of on-site heating solutions, combining innovative technology with practical functionality for industrial professionals worldwide.
