Name: Programmable Touch Screen Salt Spray Test Chamber Salt Spray Chamber Environment Test Chamber for Electronic Test
Brand: DONGGUAN YUYANG INSTRUMENT CO., LTD
SKU: YY90
Price: 855 USD
Availability: InStock

Home > Products > Environmental Test Chamber >

Programmable Touch Screen Salt Spray Test Chamber Salt Spray Chamber Environment Test Chamber for Electronic Test

programmable touch screen salt spray chamber

electronic test environment chamber

salt spray test chamber with warranty

Place of Origin:

China

Brand Name:

YUYANG

Certification:

CE,ISO: 3768, 3769, 3770; ASTM: 8117

Model Number:

YY90

Request A Quote

Programmable Touch Screen Salt Spray Test Chamber Salt Spray Chamber Environment Test Chamber for Electronic Test

Product Details

Model:

YY90

Test Chamber:

900*600*500 (W*D*H）mm

Outside Box Size:

1410*880*1280 (W*D*H）mm

Power:

220V

Supply:

Single Phase:2KW 50HZ

Standard:

ISO 9227、ASTM B-117

Saline Spray Test:

NSS(neutral)

Test Room:

35℃±1℃ 47℃±1℃

Pressure Air Barrel:

CASS（copper Acetate）

Corrosion Resistance Test:

50℃±1℃ 63℃±1℃

Highlight:

programmable touch screen salt spray chamber

electronic test environment chamber

salt spray test chamber with warranty

Payment & Shipping Terms

Minimum Order Quantity

1 set

Price

$855

Packaging Details

Plywood Case

Delivery Time

15-20 work days

Payment Terms

T/T

Supply Ability

100 sets per month

Lab Programmable Digital UV Accelerated Aging Test Chamber 220V Electronic Power 1 Year Warranty Plastic Glass Construction

Get Best Price

Video

Constant Temperature and Humidity Testing Equipment Stability Environmental for Test Chamber

Get Best Price

Climate Chamber Constant Temperature and Humidity Testing Chamber

Get Best Price

Video

Constant Temperature and Humidity Test Equipment High and Low Temperature Testing Chamber Simulated Environmental Test Chamber

Get Best Price

8618938165008

sales11@yuyangtest.com

86-769-26622869

Contact Now

Product Description

Programmable Touch Screen Salt Spray Test Chamber

Product Overview

This programmable touch screen salt spray test chamber is designed for environmental testing of electronic components, metal materials, and industrial products. The chamber meets popular testing standards including ASTM B117, ISO 9227, ISO 7253, and ASTM G85 for salt spray corrosion testing.

Testing Applications

Ideal for salt spray testing of zinc plating, salt-resistant spray paint, powder coating, stainless steel, and various surface treatments including electroplating, organic and inorganic films, anodize treatments, and anti-rust oils to evaluate corrosion resistance and establish product quality.

Design Standards Compliance

CNS: 3627, 3385, 4159, 7669, 8886
JIS: D0201, H8502, H8610, K5400, Z2371
ISO: 3768, 3769, 3770
ASTM: B117

Chamber Structure Features

Transparent chamber cover for easy observation of test samples and spray conditions
Waterproof structure between cover and body prevents salt spray overflow
Tower spraying system with salt solution filter and non-crystal nozzle for even salt spray distribution
Adjustable settlement control for precise testing conditions

Technical Specifications

Model	YY1015-60	YY1015-90	YY1015-120
Inner Box Size (L×W×H) cm	60×40×45	90×60×50	120×100×50
Outside Box Size (L×W×H) cm	107×60×118	141×88×128	190×130×140
Lab Volume	108L	270L	600L
Brine Tank Capacity	15L	25L	40L
Power	1AC220V, 10A	1AC220V, 15A	AC 1, 220V, 30A

Performance Parameters

Temperature Range: 35°C~55°C
Temperature Fluctuations: ≤±0.5°C
Temperature Uniformity: ≤±2°C
Temperature Precision: ±1°C
Spray Quantity: 1.0~2.0 ml/80cm²/hr
Test Chamber Temperature: NSS ACSS 35±1°C, CASS: 50±1°C
Saturated Air Barrel Temperature: NSS ACSS 47±1°C, CASS 63±1°C

Key Features

Low loading threshold for ergonomic loading and unloading
"Easy Open" pneumatically operated canopy with safety interlock
Dry seal gasket to prevent operator clothing from getting wet
Timed canopy lock and automatic purge system
Easily accessible salt spray atomizers in transparent acrylic
External portable salt solution tank for easy cleaning
Central viewing window for unobstructed visual access
Base castors and integrated forklift runners for easy transportation

Construction & Warranty: Durable hard PVC construction with anti-corrosion properties. Easy to clean and operate with 1-year warranty included.
