Name: Induction Smelting Steel Silver Copper Aluminum Iron Metal Gold Melting Machine
Brand: DONGGUAN YUYANG INSTRUMENT CO., LTD
SKU: YYSQ-TC-300AB (Three phase)
Price: 2000 USD
Availability: InStock

Home > Products > Electrical Test Set >

Induction Smelting Steel Silver Copper Aluminum Iron Metal Gold Melting Machine

induction metal melting machine

steel copper gold smelting furnace

aluminum iron melting equipment

Place of Origin:

China

Brand Name:

YUYANG

Certification:

Model Number:

YYSQ-TC-300AB (Three phase)

Request A Quote

Product Details

Work Power:

340V-430V

Maximum Input Current:

450A

Output Power:

300KW

Fluctuating Frequency:

5-20KHZ

The Flow Rate Of Cooling Water:

0.08-0.16Mpa 12L/Min

Water Temperature Protection Point:

50C

Product Size:

Main : 700*940*1690MM Transformer : 1200*420*770MM

Net Weight :

Main : 215kg Transformer : 198kg

Highlight:

induction metal melting machine

steel copper gold smelting furnace

aluminum iron melting equipment

Payment & Shipping Terms

Minimum Order Quantity

1 set

Price

$2000

Packaging Details

Plywood Box

Delivery Time

5-10 work days

Payment Terms

T/T, L/C, Western Union

Supply Ability

200 sets per month

High Frequency Electromagnetic Induction Heating Generator for Steel Bar in Metal & Metallurgy Machinery

Get Best Price

Video

Mini Automatic Plastic Glass Jar Sealing Machine Handheld Aluminum Foil Heat Hot Induction Packaging with Cap Lid 220v

Get Best Price

Video

15KW High Frequency Induction Heating Machine New Metal Copper Pipe Wire Welding Manufacturing Plants Construction Motor Engine

Get Best Price

Video

20-100mm Aluminum Foil Lid Plastic Jar Sealing Heat Machine Handheld Induction Bottle Foil Sealer Metal Metallurgy Machinery

Get Best Price

8613825729462

sales03@yuyangtest.com

86-769-26622869

Contact Now

Product Description

Induction Smelting Machine for Multiple Metals

This high-frequency induction heating machine efficiently melts steel, silver, copper, aluminum, iron, gold, and other metals with advanced IGBT inverter technology and automatic frequency tracking.

Key Characteristics

Advanced IGBT inverter device with automatic frequency tracking
High-frequency operation for rapid heating with 20-30% lower power consumption than electronic tube induction heating
Secure voltage operation for enhanced safety and reliability
Manual and automatic regulation with comprehensive protection against over-voltage, over-current, water shortage, phase failure, and overheating
No open flame, noise, or pollution - environmentally friendly and fire-safe
Recommended for brazing, welding, forging, hot cooperation, melting, quenching, and annealing applications

Technical Features

Utilizing advanced electrical components and innovative techniques, this high-frequency induction heating machine provides rapid, localized metal heating. It can penetrate non-metal materials to heat metals until fusion without direct contact, offering safe, economical, and pollution-free technical solutions.

Operational Advantages

Portable Design: Integrated construction saves over 80% space and 75% weight compared to traditional transformers, providing flexible heating capabilities with monolithic shell design resistant to weak acids and alkalis
Complex Metal Heating: Hand-held machine head with amorphous magnetic core material accommodates wider frequency range for irregular shaped workpieces with superior heating effects
Efficient & Safe Operation: Rapid heating within 8 seconds, stable magnetic field output, intelligent operation suitable for copper pipe welding, transformer applications, and complex welding requirements

Technical Parameters

Parameter	Specification
Model	YYSQ-TC-300AB (Three phase)
Work Power	340V-430V
Maximum Input Current	450A
Output Power	300KW
Fluctuating Frequency	5-20KHZ
Cooling Water Flow Rate	0.08-0.16Mpa 12L/Min
Water Temperature Protection	50°C
Main Unit Dimensions	700×940×1690mm
Transformer Dimensions	1200×420×770mm
Main Unit Net Weight	215kg
Transformer Net Weight	198kg

Application Areas

Metal brazing: copper and brass, tungsten steel and stainless steel, iron and copper, aluminum and copper
Glasses welding, fishing tool welding, hardware appliances welding
Carbide saw and saw-tooth welding, carbide blade welding
Jewelry and watches welding
Electronic industry: motor rotor hot-cooperation, electrode silver and tin soldering
Metal implants, bulb electrode manufacturing
Band accessory soldering, golf head production, pipe welding
Communication equipment soldering, copper coaxial cable connector soldering

Company Information & Support

Company Location: Based in Guangdong, China, operating since 2018 with global market reach including South Asia, Eastern Asia, Domestic Market, Southeast Asia, Eastern Europe, North America, Oceania, and Western Europe
Quality Assurance: Pre-production sampling and final inspection before shipment ensure consistent product quality
Product Range: Fire Testing Equipment, Environmental Test Chambers, Textile Testing Equipment, Toys Testing Equipment, Wire and Cable Test Machines
Competitive Advantage: High-tech enterprise specializing in developing and manufacturing comprehensive testing equipment solutions
Service Support: Accepts FOB, CFR, CIF, EXW delivery terms; multiple payment currencies and methods including T/T, L/C, D/P D/A, Credit Card, Western Union, Cash; English and Chinese language support
