Name: Single Column 10kN Tensile Testing Machine Digital Display for Film Packaging Rubber Textile
Brand: DONGGUAN YUYANG INSTRUMENT CO., LTD
SKU: YYD-100D
Price: 25,000.00 USD
Availability: InStock

Home > Products > Tensile Testing Machine >

Single Column 10kN Tensile Testing Machine Digital Display for Film Packaging Rubber Textile

10kN tensile testing machine digital display

single column tensile testing machine for film

tensile testing machine for rubber textile

Place of Origin:

China

Brand Name:

YUYANG

Certification:

Model Number:

YYD-100D

Request A Quote

Single Column 10kN Tensile Testing Machine Digital Display for Film Packaging Rubber Textile

Product Details

Max Load:

100kn

Load Accuracy:

Grade 1 Or Grade 0.5

Test Range:

2-100%FS Or 0.4-100%FS

Load Resolution:

1/500000FS

Test Control Mode:

3 Closed Loop Control, Stress, Strain And Displacement

Tensile/ Compression Space:

650mm

Test Width:

410mm

Deformation Accuracy:

≤±1%

Displacement Resolution:

0.01mm

Crosshead Speed Range:

0.001～500mm/min

Overall Dimensions (L*W*H):

800*500*1950mm

Power:

1kw

Supply Voltage:

1P 220V±10%,50-60HZ,500W

N.W.:

500kg

Operating Temperature:

0 To +38°C (+32 To +100°F)

Humidity Range:

10% To 90% Non-condensing

Highlight:

10kN tensile testing machine digital display

single column tensile testing machine for film

tensile testing machine for rubber textile

Payment & Shipping Terms

Minimum Order Quantity

1 set

Price

pending

Packaging Details

Plywood Box

Delivery Time

5-10 work days

Payment Terms

T/T, L/C, Western Union

Supply Ability

200 sets per month

Textile Fabric Tensile Testing Machine 10kN with Constant Rate of Extension CRE ASTM ISO

Get Best Price

Geotextile Tensile Testing Machine 50kN 100kN Wide Specimen Grip ASTM D4595 ISO 10319

Get Best Price

500kN High Capacity Tensile Testing Machine for Heavy Metal Steel Structural Material Testing

Get Best Price

Film Packaging Tensile Tester 5kN ASTM D882 D1708 for PE PP PVC Polyester Film Lab

Get Best Price

8613825729462

sales03@yuyangtest.com

86-769-26622869

Contact Now

Product Description

Single Column 10kN Tensile Testing Machine Digital Display

Professional digital display tensile testing machine designed for film packaging, rubber, and textile materials with precise measurement capabilities.

Technical Specifications

Control Mode	Digital Display System
Model	YYS-5D \| YYS-10D \| YYS-20D \| YYS-30D \| YYS-50D \| YYS-100D
Max Load	5KN \| 10KN \| 20KN \| 30KN \| 50KN \| 100KN
Load Accuracy	Grade 1
Test Range	2-100%FS
Tensile/Compression Space	800mm \| 789mm \| 750mm \| 650mm
Test Width	300mm \| 315mm \| 400mm \| 410mm
Deformation Accuracy	≤±1%
Displacement Resolution	0.01m
Crosshead Speed Range	0.001～500mm/min
Overall Dimensions (LWH)	4203001500mm \| 6634301700mm \| 7705001830mm \| 8005001950mm
Power	0.3kw \| 0.75kw \| 1kw
Operating Temperature	0 to +38°C (+32 to +100°F)
Humidity Range	10% to 90% non-condensing

Additional Options

Extra wide and/or extra height frames are available
Power supply system is completely customizable
