Name: ISO 14616 Standard Heat Shrinkage Testing Equipment with ±0.5°C Accuracy for 3 Groups Specimen Testing
Brand: DONGGUAN YUYANG INSTRUMENT CO., LTD
SKU: YYP-009
Price: 1999 USD
Availability: InStock

Home > Products > Package Testing Equipment >

ISO 14616 Standard Heat Shrinkage Testing Equipment with ±0.5°C Accuracy for 3 Groups Specimen Testing

ISO 14616 Standard Heat Shrinkage Testing Equipment

±0.5°C Accuracy Film Heat Shrink Tester

3 Groups Specimen Testing Package Testing Equipment

Place of Origin:

China

Brand Name:

YUYANG

Certification:

ISO

Model Number:

YYP-009

Request A Quote

ISO 14616 Standard Heat Shrinkage Testing Equipment with ±0.5°C Accuracy for 3 Groups Specimen Testing

Product Details

Model:

YY009

Capacity Range:

0.2 ~ 30 N (standard) Customization Available

Accuracy:

±0.5°C

Displacement Range:

0.125 ~ 70 Mm

Temperature Range:

Room Temperature ~ 210°C

Number Of Specimens:

1 ~ 3 Groups

Specimen Size:

130 Mm X 15 Mm (Standard)

Gas Supply:

Dry Air (outside Of Supply Scope)

Port Size:

Φ6 Mm PU Tubing

Instrument Dimension:

735 Mm (L) X 490 Mm (W) X 391 Mm (H)

Power Supply:

220VAC 50Hz / 120VAC 60Hz

Net Weight:

0-100 Kg

Highlight:

ISO 14616 Standard Heat Shrinkage Testing Equipment

±0.5°C Accuracy Film Heat Shrink Tester

3 Groups Specimen Testing Package Testing Equipment

Payment & Shipping Terms

Minimum Order Quantity

Price

1999

Packaging Details

Standard Wooden Case

Delivery Time

10 days

Supply Ability

15 sets per month

ISO 14616 Standard Heat Shrink Tester with ±0.5°C Accuracy for 3 Groups Specimen Testing

Get Best Price

ISO 14616 Standard Heat Shrinkage Testing Equipment with ±0.5°C Accuracy for 3 Groups Specimen Testing

Get Best Price

Micro-Computer Controlled Friction Package Testing Equipment with Double Heating Sealing Jaws Compliant with ASTM D1894 Standard

Get Best Price

PLC Control Hot Tack Tester with Double Heating Sealing Jaws and 7 Inch TFT Touch Screen for Heat Seal Strength Test

Get Best Price

8613825729462

sales03@yuyangtest.com

86-769-26622869

Contact Now

Product Description

Food Package Wrapping Heat Shrinkage Testing Equipment, Film Heat Shrink Tester

Product Overview

Food Package Wrapping Heat Shrinkage Testing Equipment is designed based on the ISO 14616 international standard. It is applicable to the precisely quantitative determination of the shrinking force, contracting force and shrinkage ratio for heat-shrinkable plastic films during the thermal shrinkage process.

Key Features

3 groups of distinct or identical specimens can be tested at one operation
Shrinkage parameters can be accurately obtained by high precision load cell and displacement transducer
The system displays the real-time value of shrinking force, contracting force and shrinkage ratio
Intelligent reminder for sensor calibration guarantees a safe test environment
Viewing and printing of historical data are available in this instrument

Shrinking Force and Contracting Force

Test the shrinking or contracting force of heat-shrinkable films at specified test conditions

Shrinkage Ratio

Test the shrinkage ratio of heat-shrinkable films at specified test conditions
