Name: Horizontal Optical Profile Projector Optical Comparator with 0.001 mm Measuring Resolution, Φ300 mm Projection Screen and LED Cold Light Source
Brand: DONGGUAN YUYANG INSTRUMENT CO., LTD
SKU: YY-4025
Price: 3,000.00 USD
Availability: InStock

Home > Products > Horizontal Flammability Tester >

Horizontal Optical Profile Projector Optical Comparator with 0.001 mm Measuring Resolution, Φ300 mm Projection Screen and LED Cold Light Source

0.001 mm Horizontal Optical Profile Projector

Φ300 mm Projection Screen Optical Comparator

LED Cold Light Source Profile Projector

Place of Origin:

Guangdong

Brand Name:

YuYang

Certification:

Model Number:

YY-4025

Request A Quote

Product Details

Projection Screen:

Φ300 Mm

Magnification:

10X / 20X / 50X / 100X (Optional)

Worktable Travel:

(X×Y)150 × 50 Mm

Z-axis Travel:

80 Mm

Measuring Resolution:

0.001 Mm

Optical System:

Transmitted & Reflected Illumination

Light Source:

LED Cold Light Source

Display:

Digital DRO Display

Highlight:

0.001 mm Horizontal Optical Profile Projector

Φ300 mm Projection Screen Optical Comparator

LED Cold Light Source Profile Projector

Payment & Shipping Terms

Minimum Order Quantity

MOQ:1SET

Price

negotiate

Packaging Details

wooden box

Delivery Time

6-30 days

Payment Terms

L/C,D/A,D/P,T/T

Supply Ability

10 Set/Sets per Month

0.001 mm Measuring Resolution Horizontal Profile Projector Optical Comparator with Φ300 mm Projection Screen and LED Cold Light Source

Get Best Price

0.001 mm Measuring Resolution Profile Projector Optical Comparator with Φ300 mm Projection Screen and LED Cold Light Source

Get Best Price

Horizontal Profile Projector Optical Comparator with 0.001 mm Measuring Resolution, Φ300 mm Projection Screen and LED Cold Light Source

Get Best Price

Non-contact Optical Profile Projector with Horizontal Optical Axis and LED Cold Light Source for Precision Inspection

Get Best Price

8618938576621

sales05@yuyangtest.com

86-769-26622869

Contact Now

Product Description

Horizontal Optical Profile Measuring Projector

The horizontal profile projector is an optical comparator engineered for accurate, non-contact dimensional inspection of small and medium-sized workpieces. By projecting a magnified silhouette of the part onto a viewing screen, it enables operators to verify profiles, angles, threads, and surface features with high repeatability — making it a dependable instrument for quality control, tool rooms, and production inspection lines.

Key Measurement Capabilities

Non-contact optical measurement of length, diameter, angle, radius, and thread profiles
Magnified silhouette projection for fast visual comparison against overlay charts
Stable horizontal optical axis suited to shaft-type and elongated workpieces
Precise stage travel for repeatable coordinate positioning and dimension verification
Well-suited to incoming inspection, first-article checks, and in-process quality control

Typical Applications

Machined parts, turned components, and precision fasteners
Cutting tools, dies, molds, and stamping profiles
Threads, gears, and small plastic or metal molded parts
Electronics, watch components, and other miniature precision parts

Why Choose This Optical Comparator

The horizontal configuration provides a rigid, ergonomic platform for inspecting elongated parts while keeping the workpiece securely supported. Combined with clear silhouette imaging and precise stage movement, it delivers the measurement confidence required in industrial inspection environments — without the risk of surface contact or part deformation.
