70mm X 70mm Flammability Test Apparatus For Blanket Fabric Flame Retardant Test

70mm X 70mm Flammability Test Apparatus For Blanket Fabric Flame Retardant Test

flame test equipment

flammability test chamber

Place of Origin:

China

Brand Name:

YUYANG

Certification:

ASTM D4151

Model Number:

YY125

Contact Us
Request A Quote
Product Details
Product Name:
Flammability Test Chamber
Usage:
Automotive Interior Burn Resistance
Test Chamber:
37cmX22cmX35cm
Clamp:
2.5”
Flame Length:
16mm
Specimen Dimension:
70mmx70mm
Dimension:
42x26x52cm (L×W×H)
Weight:
20 Kg
Highlight:

flame test equipment

,

flammability test chamber

Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
Negotiation
Packaging Details
Plywood Box
Delivery Time
10-15 work days
Payment Terms
T/T, L/C, Western Union
Supply Ability
3 sets per month
Product Description



ASTM D4151 Blanket Fabric Flame Retardant Surface Flame Spread Performance Flammability Testing Equipment





Description:



Blanket Flammability Tester to test blanket fabric flame retardant performance and fabric surface flame spread performance, the test method is within the stipulated time, to standardize the flame was carried out on the sample surface combustion, the combustion of standard test paper, to look at the degree of damage or discoloration, and fabric for grading evaluation of the test.





Specification:



Test Chamber: 37cmX22cmX35cm, top gas vent diameter: 12.7mm*12

Clamp: 2.5”

flame length:16mm

firing time:30s

Specimen dimension: 70mmx70mm

Dimension: 42x26x52cm (L×W×H)

Weight: ≈20Kg

Power: 1∮ AC 220V 50Hz 3A

Standard: ASTM D4151

Accessories: Micro gas tanks , Micro gas cylinders 2pcs, clamp 1set, clip 2pcs, power line 1pcs
