DONGGUAN YUYANG INSTRUMENT CO.,LTD
China Good Quality Manufacturer of Testing Equipment
Place of Origin: | China |
Brand Name: | YUYANG |
Certification: | JIS-L0846、JIS-L0847、JIS-L0848、JIS-L0854 |
Model Number: | YY1510 |
Minimum Order Quantity: | 1 |
---|---|
Price: | Negotiation |
Packaging Details: | Plywood case |
Delivery Time: | 8-10days |
Payment Terms: | Western Union, T/T, L/C,Paypal |
Supply Ability: | 4pcs /week |
ISO: | 40×100 Mm,115×60×1.5 Mm(D) | Weight: | 8KG |
---|---|---|---|
Dimension (W×D×H): | 196x77x220 Mm | AATCC: | 60×60 Mm |
Product Name: | Footwear Testing Equipment | Usage: | Perspiration Tester |
High Light: | fatigue tester machine,perspiration tester |
High Precision 8kg ISO AATCC JIS Perspiration Testing Equipment for Footwear
Description:
Competely and averagely soak specimen into acid and alkaline artificial sweat liquid for 30 minutes. Use the meter to press it then put into oven at temperature of 37°C for 4 hours. Take out specimen from oven to appraise grade of dry-endurance against comparision of grey scale mark after dry.
Specification:
Specification |
Specimen |
Acrylic plate |
Load |
ISO |
40×100 mm |
115×60×1.5 mm(D) |
5 kg |
JIS (A) |
60×60 mm |
115×63×1.5~3mm(D) |
4.6 kg |
JIS (B) |
40×100 mm |
155×63×1.5~3mm(D) |
5.1 kg |
AATCC |
60×60 mm |
_ |
4.5 kg |
Model |
AATCC |
JIS |
Dimension (W×D×H) |
196x77x220 mm |
142x74x244 mm |
Weight |
8 kg |
Accessories such as the different grips, elongation measuring-devices..., etc. are
equipped according to the requirements specified in the contract; our sales
representative will also give the proper suggestions to the customers beforehand.
