MT182 Alcohol Burner Combustion Testing Machine With 150mm - 180mm Flame Height

MT182 Alcohol Burner Combustion Testing Machine With 150mm - 180mm Flame Height

  • MT182 Alcohol Burner Combustion Testing Machine With 150mm - 180mm Flame Height
  • MT182 Alcohol Burner Combustion Testing Machine With 150mm - 180mm Flame Height
  • MT182 Alcohol Burner Combustion Testing Machine With 150mm - 180mm Flame Height
MT182 Alcohol Burner Combustion Testing Machine With 150mm - 180mm Flame Height
Product Details:
Place of Origin: China
Brand Name: YUYANG
Certification: MT182, MT141, MT914
Model Number: YY166
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Plywood Box
Delivery Time: 15 work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 10 sets per quarter
Contact Now
Detailed Product Description
Product Name: Flammability Testing Equipment Usage: Alcohol Burner Combustion Test
Standard: MT182, MT141, MT914 Combustion Chamber: 660 * 660 * 1050mm
Control Box: 910 * 660 * 1050mm Combustion Time: 0 ~ 99.99 Seconds
Flame Height: 150mm-180mm Power: AC220v; 50Hz; 50W
High Light:

flame test equipment

,

flammability test apparatus





MT182 Alcohol Burner Combustion Testing Machine with 150mm-180mm Flame Height





Description:



This tester is developed and manufactured in accordance with MT182; The instrument is suitable for non-metallic products for coal mining under laboratory conditions to do the alcohol burner combustion test burning test;





Standard:



MT182, MT914, MT141 Plastic net protecting top-plane in coal mining




Technical Parameters:


1. Test box is equipped with exhaust fan and stalinite window.
2. The test box is used with stainless steel cabinet making.
3. Equipped with flame temperature calibration package and flame height detection ruler
4. PLC + HMI automatic control, accurate timing, automatic calculate the samples to get the average value of the timing;
5. Timing accuracy up to 0.1s
6. The combustion chamber size is 660 * 660 * 1050mm
7. Control box size 910 * 660 * 1050mm




Alcohol burner combustion tester instrument features


1. Alcohol burner fit to standard required;
2. Burning time is recorded automatic;
3. The flame height can be adjusted;
4. With a special exhaust system, exhaust gas discharged automatically.

Alcohol burner combustion test Instrument Index

1. The combustion time: 0 ~ 99.99 seconds could be set arbitrardily, accuracy ± 0.01 seconds.
2. Flame and flameless timer: 0 ~ 99.99 seconds, accuracy: ± 0.01 s;
3. Power Supply: AC220v; 50Hz; 50W;
4. Fuel: 5% (V / V) methanol and 95% (V / V) ethanol mixture (customer self-made);
5. The flame height: 150mm-180mm;





MT182 Alcohol Burner Combustion Testing Machine With 150mm - 180mm Flame Height 0
