Place of Origin:
CHINA
Brand Name:
YUYANG
Certification:
ISO13485
Model Number:
YYE032
YYE032 Facial Particle Filter Tester (PFE)
Product Introduction Description
Particulate Filtration Efficiency Tester is suitable for fast, accurate and stable detection of particulate filtering efficiency of various medical and daily protective masks, respirators, etc.
With clean compressed air, the prepared NaCl solution or a similar solution such as DEHS/PAO are sprayed from the aerosol generator. After passing through a classifier (inertia principle), unneeded large particles are collected into the collection bottle, and particles meeting the requirements enter into the test system from the nozzle of aerosol generator
Parameters
| Test flow range | 15L / min ~ 100L / min, accuracy 2% |
| The cross-sectional area through which the air flows | 100cm² |
| Resistance test range | 0 ~ 1000Pa, accuracy can reach 0.1Pa |
| Filtering efficiency test range | 0 ~ 99.999%, resolution 0.001% |
| Est particle size | 0.3um |
| Aeroso Sodium chloride concentration | Salinity 10mg / m '~ 25mg / m,Oily 50mg / m ~ 200mg / m |
| Fog dust source | NaC1, DEHS |
| Test time | resistance is tested separately for 5s, and efficiency and resistance are tested simultaneously for 70s |
| Structural composition | particle generator, flow detection device, concentration detection device |
| Number of samples | 1 |
| Power | 220V, 50Hz, 1KW |
| Dimensions | L800xW600xH1650mm |
| Weight | 120Kg approx |
