Description:
Mainly used for measuring the detection of various electric screwdriver, pneumatic screwdriver, torque screwdriver, and the size of the torque wrench torsion, correction of electric screwdriver, pneumatic screwdriver, torque screwdriver, and torsion torque wrench, torque, conforms to the need, also can measure the torque of other tools, such as: all kinds of fixture, etc.
Feature:
1,Torsion direction display.
2,Automatic alarm Settings.
3,Can be stored and print 10 test data.
4,Calculating the average store data automatically.
5,Can print the test curve.
6,Kgf) Cm/Lbf) in/N.m transformation.
7,With a peak value holding function.
8,Nickel metal hydride battery display.
9,1 to 60 minutes of adjustable without automatic shutdown operation designed to save power.
10,Automatic charge control.
11,Light touch keys to operation.
Specification:
|
Measuring range
KGf.cm
N.m
Lbf.in
|
1.5-100.0
0.15-10.00
1.5-90.0
|
| Precision |
Plus or minus 0.5% |
| Sampling rate |
600HZ |
| The power supply |
Nickel metal hydride battery: 1.2 V x 6 |
| Charging time |
The < 8 hours |
| When charged continuous use time of the battery |
50 hours |
| The life of the battery |
Back to 500 or higher |
| Size |
1 2mm x 230rnm x 651mm |
| Weight |
2 kg |
| The charger |
Input: AC 50 HZ, 220 v output: DC 12 v, 300 ma |
Standard: ISO8124-1 5.24.5 Torque test EN71-1 8.3 TORQUE TEST
