Name: UL817 Wire and Cable Abrupt Pull Testing Equipment Electronic Tester Machine
Brand: DONGGUAN YUYANG INSTRUMENT CO., LTD
SKU: YYW014
Price: 1000 USD
Availability: InStock

Home > products > Wire Testing Equipment >

UL817 Wire and Cable Abrupt Pull Testing Equipment Electronic Tester Machine

Combustion Wire Testing Equipment

25mm Wire Testing Equipment

IEC707 fatigue testing machine

Place of Origin:

China

Brand Name:

YUYANG

Certification:

Model Number:

YYW014

Request A Quote

UL817 Wire and Cable Abrupt Pull Testing Equipment Electronic Tester Machine

Product Details

Product Name:

Wire And Cable Abrupt Pull Testing Equipment

Load Weight:

- 15 Lb 6

Power Up Time:

0 ~ 99 Min Adjustable

Maxcapacity:

>1000KN

Tensile Height:

254 Mm (10 "), 178 Mm (7") 2 Stalls

Max Capacity:

>1000KN

Mass Scope Of Workpiece:

1000kg

Highlight:

Combustion Wire Testing Equipment

25mm Wire Testing Equipment

IEC707 fatigue testing machine

Payment & Shipping Terms

Minimum Order Quantity

1PCS

Price

$1000

Packaging Details

Wooden Box

Delivery Time

7-30 Days

Payment Terms

T/T

Single Insulated Cable Testing Equipment , IEC 60332-1 Flame Propagation Test Apparatus

Get Best Price

IEC 60332-3 Vertical Flammability Tester For Burning Behaviour Of Bunched Cables

Get Best Price

IEC60331 Wire Testing Equipment Cable Fire Resistance Test For Circuit Integrity Under Fire Conditions

Get Best Price

Halogen Acid Gas Release Corrosion Testing Equipment IEC 60754-1&2 Test Standard

Get Best Price

+86-13825723571

sales002@yuyangtest.com

86-769-26622869

Contact Now

Product Description

UL817 Wire and Cable Abrupt Pull Testing Equipment Electronic Tester Machine 0

Production details:

This tester is specialized in testing abrupt / rotary pull strength between the blades and conductor . Fix

the blades to the plug fixture and tie the cord to the grip with stripped conductors outside on which the

crocodile clips clamp . Afterward , hang the weight assembly onto the grip hook to perform the above

test . It can also execute the current test independently.

Technical Parameters:

1. Power supply: AC 220 V, 50 Hz, 10 A;

2. Load current: AC 6 ~ 12 V, 40 A;

3. Power up time: 0 ~ 99 min adjustable;

4. Rotation time: ≤ 15 S;

5. Tensile height: 254 mm (10 "), 178 mm (7") 2 stalls;

6. Number of poles: 0 ~ 9999 times can be preset;

7. Weight: Rally weight - 2.5 Lb 6;

Rotating weights - 3 Lb 6;

Load weight - 15 Lb 6;

8. Station: 6

9. Reference standard: UL817 Article 99.1

Specification:

Order information	YYW-014-1(6 sets), YYW-014-2 (3sets),
Specimen Volume	6 sets / 3 sets
Abrupt Pull weight	2.5LB ×6 pcs
Rotation Weight	3LB ×6 pcs
Load Weight	15LB ×6 pcs
Load Current	0-50A12V (adjustable)
Counter	0-999999 (adjustable)
Abrupt Pull Height	7”/10” (adjustable)
Power	AC220V/ 50hz
