| Place of Origin: | China |
| Brand Name: | YUYANG |
| Certification: | CE |
| Model Number: | YYD001 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | negotiable |
| Packaging Details: | wooden box |
| Delivery Time: | 5-25 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 200 pcs per month |
| Product Name: | Food/textile Metal Detector | Material: | Stainless Steel |
|---|---|---|---|
| Machine Length: | 1550mm | Speed Of Transmission: | 18-40 Meter/minute |
| Height Of Inspection Window(cm): | 10 | Width Of Inspection Window(cm): | 40 |
| Detecting Width: | 40-120CM | Detecting Height: | 10-50CM |
| Warranty: | 1.5 Year | Application: | Food/textile/Plastic Production |
| High Light: | 40meter/minute Metal Detection Machine,18m/min Metal Detection Machine,Electromagnetic Textile Metal Detector |
||
Digital Sensitive Metal Detection Machine For Pharma Body Food / Textile
Description:
Transmission type all-digital metal detection machine is a new generation of microcomputer intelligent metal detection equipment launched by the company. The product has high sensitivity and stable performance. Besides, it breaks through the technical bottleneck that most of the equipment only responds sensitively to magnetic substances, and has a good elimination performance for products with moisture and frozen products.The device can detect metals such as iron and non-iron, and can be widely used for metal detection in demanding objects such as food, medicine and toys.
Use:
It was mainly used for: sauces, sausages, dumplings, ham, soup, sugar products, pickled foods, salted foods, fast food and other non-food industries, the high detection sensitivity, anti-interference ability and waterproof standard for hard-working condition, to detect the mixed or lost needle, wire, or lead, copper, aluminium, tin, stainless steel and other kinds of metal in food, raw materials or products.
Feature:
1. Double circuit electromagnetic wave detection, new analog circuit and digital circuit combination, improve the sensitivity and reliability of detection.
2. The new type of touch screen input and composition of large scale integrated circuit improve the intelligence of detection (LIQUID crystal type).
3. User-friendly interface design, multi-language operation, the whole process is simple and intuitive, human-machine interface at a glance (LIQUID crystal).
4. Dynamic zero point voltage tracking, automatic learning detection function, reduce personnel operation.
5. Wide adjustable range of sensitivity, with reverse detection function (no alarm for metal products, no alarm for metal products).
6. When metal is detected, sound, light and alarm will be given at the same time, and the machine will stop or kick out the unqualified products (optional functions).
Parameter:
| Detected Height(mm) | 300 |
| Belt Width(mm) | 450 |
| Belt Length | 1600 |
| Detector sensitivity(mm) | Fe 3 |
| SUS 4 | |
| N-Fe 3.5 | |
| Speed of belt |
25M/min (Fixed speed) ; If you need adjust 5-40 M/min , please inform us before order |
| Load ability | 18KG |
| Count | 100 |
| Warning method | sound and light alarm Or reject unqualified products directly |
| Reject Ways | when has auto-reject system ,belt continue and rejecting the goods |
| Material | 304 stainless steel |
| Application | Non-package ,plastic package ,paper bag or box (non-metallic) product |
| Work Environment | Temperature -10℃-40℃ ,relative humility 30-90% |
