Electrical Test Set Data Resolution 0.001mm Three Axis Travel Mm 200*100

Product Description:

Lectrical Test Set Data Resolution 0.001mm Three Axis Travel Travel Mm 200*100

Optical Image Measuring Instrument is a technologically advanced and reliable measuring instrument which is a combination of optical, mechanical, electronics & computer image processing technologies. This instrument magnifies the object to be measured by means of optical amplification system and then uses a CCD camera system to capture the image characteristics and transfer them to the computer for analysis.

The main features of using the Optical Image Measuring Instrument are as follows:

• High precision: as it incorporates modern optical and electronic technologies, the measurements of this instrument are of great accuracy at micron level.
• Rapid detection: with the help of a computer to identify & process image features, it can detect very quickly.
• Easy to operate: an easy-to-understand operation interface and automation commands make measurement easy and more convenient.
• Widely used: optical image measuring instrument is widely used in the areas of electronics, machinery, mold-making, automobiles for detecting precision parts & components.

Today the usage of Optical Image Measuring Instrument in various industries has gone up, as it considerably increases the quality of products & efficiency of production.

Features:

Optical Image Measuring Instruments have many advantages. One of the most notable advantages is its ability to detect complex parts. This includes curves, surfaces, and even holes. Furthermore, it can detect multiple parts at the same time. Another advantage is that the instrument is non-contact based. This prevents errors from occurring due to contact, as well as preserving the measured object.

In addition, the Optical Image Measuring Instruments have a high degree of automation. This means that it can identify and process image features automatically through a computer. This not only increases the speed and accuracy of measurement, but it also save time and energy.

Finally, the instrument has a compact design, making it easy to maintain and repair. Thanks to its durability, it can work stably for a long time.

Technical Parameters:

The XYZ-Axis travels spans up to 200mm, 100mm, and 200mm, respectively. The measuring accuracy is 3+L/200 um. The resolution for both the X-Axis and Y-Axis is 0.001mm, and the screen size has a diameter of 312mm (with a useable range >300mm).Rotations can spanning up to 0° to 360°, with a resolution of 1' and 0.01° respectively. The magnification options for the lens includes 10X,20X, 50X, and 100X. The object view apsects covers 30mm, 15mm,6mm, and 3mm. The working distance comprises 77.7mm, 44.3mm, 38.4mm, and 25.3mm. The maximum height of the workpiece ranges90mm for all parameters. The data processing system, written in English, is DP-100 Multi Function System that can compile data to measure points, lines, circles, angles, and distances.

The illumination is formed by a 24V/150W halogen lamp. The power carries 110V/220V (AC), with a frequency duration of 50/60Hz. The total power stands at approximately 400W and is avaialble for both transmission and reflection. The forced air cooling ensures the temperature does not rise. The demensions of the respecitve product is 1750*920*1700mm, and the weight stands at 170kg.

Applications:

The YUYANG YYM-2010 High Precision Electronic Projector is a high and stable image measuring instrument with a total magnification ranging from 30 to 230X, a lens magnification from 0.7 to 4.5X, and a WD of 95mm. It has a data resolution of 0.001mm, weighs 170kg, and has a measurement accuracy of ±3.5μm. This CNC Video Measuring Machine is perfect for measuring precise dimensions of objects in a highly accurate manner in a wide variety of industrial, commercial and research settings.
