| Total Magnification: | 30~230X | Data Resolution: | 0.001mm |
|---|---|---|---|
| Weight(kg): | 170 | Dimension(L)*(W)*(H): | 500*700*1100 |
| Camera: | SONY1 / 3" Color CCD Camera | Lens Magnification: | 0.7~4.5X WD:95mm |
| Measurement Accuracy: | ±3.5μm | Resolution: | 0.001 (mm) |
| High Light: | Precise Electrical Test Set,0.001Mm Resolution Electrical Test Set |
||
Precise Electrical Test Set Dimension L * W * H - 500*700*1100 Resolution - 0.001 Mm
Optical Image Measuring Instrument is a highly advanced measuring instrument combining optical, mechanical, electronic and computer image processing technologies. Its primary purpose is to enlarge the target measurement object through an optical amplification system. Then, the CCD camera system collects the image characteristics and sends it over to the computer for analysis.
The most distinguishing features of Optical Image Measuring Instrument are its high precision, rapid detection, easy to use operation interface and wide usage scope. It introduces advanced optical and electronic technology, thereby leading to a measurement precision at the micron level. Additionally, its automated feature identification and processing speed shorten the detection process, and the user-friendly operation interface is convenient for operators.
Optical Image Measuring Instrument is employed in a variety of industries, such as electronics, machinery, mold, automotive, to perform the inspection and quality control of the contour and surface figure of precision parts. Its presence facilitates modern industrial production greatly, because it not only improves the product quality, but also increases the production efficiency.
Optical Image Measuring Instruments has a lot of advantages to offer. The first advantage is that they can detect complex parts. The instrument is able to pick up curves, surfaces and holes with multiple parts at the same time.
The second advantage is that they are able to measure without contact. This non-contact measurement is able to protect the part from damage as well as ensuring the accuracy of the measurements.
Thirdly, the degree of automation is high. The computer is able to identify and process image features and measurements are automated. This makes for an increase in speed and accuracy during the measurement process.
The final advantage of using Optical Image Measuring Instrument is maintenance and repair. It is easy to maintain and repair due to its compact design and a service life of long duration.
This tool performs measuring functions with impressive accuracy, boasting a 3+L/200µm measuring accuracy. The X-axis and Y-axis travel distances are 200mm and 100mm, respectively, while the Z-axis travels 200mm throughout its focus process. The resolution for the X-axis and Y-axis is 0.001mm, while that for the X-axis and Y-axis is 1´ or 0.01°.
The lens magnification can be altered to ten, twenty, fifty, or one hundred times, and the object view through the lens includes Ø30, Ø15, Ø6, and Ø3 options. The working distance is variable, depending on the magnification setting, ranging from 77.7mm, 44.3mm, 38.4mm, to 25.3mm, respectively. Moreover, the maximum workpiece height is 90mm with each magnification.
The data processing system is the DP-100 multi-function system, allowing the user to process data and measure points, lines, circles, angles, and distances. The transmission and reflection illumination is backed up by a 24V/150W halogen lamp, and the total power consumption is 400W, regulated by 110V/220V AC 50/60Hz. The cooling system works using forced air, and both the dimensions and weight of the unit are 1750*920*1700mm and 170kg.
YUYANG YYM-2010 CNC Video Measuring Machine is a high precision electronic projector specifically designed for manufacturing industries. It is made with advanced technology and is manufactured with utmost precision by DONGGUAN. This CNC Video Measuring Machine is highly efficient and provides a resolution of 0.001mm. It has a dimension of 500*700*1100mm and has three axis travel Travel of 200*100mm. This machine is program controlled and has a lens magnification of 0.7~4.5X with a WD of 95mm. It is the perfect equipment for any manufacturing industry and is an ideal choice for high precision measuring.
