50HZ 30W High Precision Electronic Projector With Convenient 500*700*1100 Dimensions

Product Description:

50HZ 30W High Precision Electronic Projector With Convenient 500*700*1100 Dimensions

Optical Image Measuring Instrument is a highly precise, efficient and reliable instrument, which integrates optics, mechanics, electronics and computer image processing technologies. In its operation, an optical amplification system is used to enlarge the studied object, and its CCD camera system will subsequently captures the image characteristics and, consequently, send them to the computing unit for further analysis.

Generally speaking, Optical Image Measuring Instrument is mainly used to measure the contour and surface of complex precision parts, as well as to evaluate the size, angles and positions - increasing accuracy during microscopic examination and quality assessment.

These features make Optical Image Measuring Instrument a viable option thanks to its:

• High precision: Optical Image Measuring Instrument adopts advanced optical and electronic technology, thus ensuring a micron level of accuracy.
• Rapid detection: an automated image feature identification, enabled by the use of computers, assists the speedy collection and assessment of data.
• User-friendly operation with automated functions, making the process much easier and more efficient.
• Widely applicable in industries such as electronics, machinery, mold, and automotive.

Overall, Optical Image Measuring Instrument is an invaluable tool for modern manufacturing industry, precisely measuring and inspecting parts, and thus, escalating product quality and production efficiency.

Features:

Optical image measuring instruments offer many advantages. Firstly, they can detect complex parts including curves, surfaces, and holes simultaneously. Additionally, the images can be measured without needing to physically contact the object. This protects the object and also eliminates errors that can arise from contact with measuring instruments. Furthermore, the automation of the image measurement process makes the measurement process both fast and accurate. Finally, optical image measuring instruments usually have a compact design which makes them easy to maintain and use over a long period of time.

Technical Parameters:

The X-axis travel is 200mm, the Y-axis travel is 100mm, and the Z-axis travel is 200mm (for focus). The measuring accuracy reaches up to 3+L/200 um, and the resolution of X-axis and Y-axis are both 0.001 mm. The size of the screen is Ø 312, the rotary range is 0°~360°, with resolution of 1´ or 0.01°. It offers 4 different lens magnifications of 10X, 20X, 50X and 100X with the corresponding object views of Ø30, Ø15, Ø6 and Ø3, as well as the working distances of 77.7, 44.3, 38.4 and 25.3. The max. workpiece height of each is 90mm.

The DP-100multi-function data processing system, which appears in English, is used to gather data and measure points, lines, circles, angles and distances. The illumination of transmission and reflection is 24V/150W-halogen lamp. The power is 110V/220V (AC) with a frequency of 50/60HZ and a total power of 400W, cooled with forced air cooling. The size of the device is 1750*920*1700mm and the weight is 170kg.

Applications:

The YUYANG YYM-2010 Profile Projector is the most advanced electrical test set on the market. This state-of-the-art profile projector is made in Dongguan, and has a power capacity of 220/110V (AC), 50Hz, 30W. It also features a SONY 1/3" color CCD camera and has a dimension of 500*700*1100mm. The data resolution is incredibly precise at 0.001mm and the weight is 170kg.

The YUYANG YYM-2010 Profile Projector is perfect for any 2D optical coordinate measuring CNC machine, providing reliable and accurate measurements. Its superior optics and illumination system make it an ideal choice for profile projector applications. The YYM-2010 is also user-friendly and offers exceptional reliability and safety when used in high-end applications.

The YUYANG YYM-2010 Profile Projector is the perfect electrical test set for any professional. Its advanced features and superior performance make it the ideal choice for any industrial or laboratory application. This profile projector is sure to provide years of reliable and accurate testing.
