| Object View: | 7~1.1mm | Lighting: | Surface Light And Transmission Light Are Used LED, Brightness Adjustable |
|---|---|---|---|
| Weight(kg): | 170 | Measurement Accuracy: | ±3.5μm |
| Dimension(L)*(W)*(H): | 500*700*1100 | Data Resolution: | 0.001mm |
| Three Axis Travel Travel(mm): | 200*100 | Mode Of Operation: | Program Control |
| High Light: | 4.5X Lens Magnification Electrical Test Set,0.7 Lens Magnification Electrical Test Set |
||
Enhanced Inspection Capability With 0.7-4.5X Lens Magnification Electrical Test Set
Optical Image Measuring Instrument is a high-accuracy tool that integrates optical, mechanical, electronic, and computer image
processing technologies. It uses an optical amplification system to enlarge the measured object which are then picked up by CCD cameras and sent to a computer for analysis. OIMI’s main purpose is to measure the dimensions, angles, and positions of complex precision parts based on contour and surface shape.
OIMI has many outstanding features. Firstly, it is highly precise due to its use of advanced optical and electronic technology, which enables it to measure within the micron range. Additionally, OIMI has the ability to rapidly detect and identify image features through an automatic and computer-guided process. Moreover, it features an easy-to-use onboard software interface and is equipped with semi-automated functions to simplify manual measurements. Furthermore, OIMI has a wide range of applications in electronics, machinery, molds, and automotive industries, playing an important role in quality control and process optimization.
All in all, OIMI enables manufacturers to increase their product quality and production efficiency. With the help of OIMI, many companies in modern manufacturing industry are able to sharply improve their output.
Optical Image Measuring Instruments offer many advantages, such as in the detection of complex parts. Composed of sophisticated curves, surfaces, and holes, these instruments are capable of detecting multiple parts simultaneously.
Furthermore, Optical Image Measuring Instruments are able to conduct non-contact measurements, helping to protect the object and avoid any errors caused by contact.
This method also boasts a high degree of automation. By utilizing computer processing for feature identification and automated measurement, accuracies and speeds of measurement are greatly improved.
All of this can be enjoyed with the peace of mind that comes with a compact design that is easy to maintain and repair. As a result, these efficient machines can work stably for extended periods of time.
The X-axis travel is 200mm and the Y-axis travel is 100mm. The Z-axis travels 200mm (for focus). The measuring accuracy is 3+L/200 um. The resolution of the X-axis and Y-axis are both 0.001 mm. The screen size is Ø 312, Used range > Ø300 (with the meter line). The screen rotary range is 0° to 360°, with a resolution of 1´ or 0.01°. The lens Magnification has four options: 10X, 20X, 50X and 100X. The Object view in mm is Ø30, Ø15, Ø6 and Ø3. The Working distance in mm is 77.7, 44.3, 38.4 and 25.3. The max. workpiece height is 90mm for all four options. The Data Processing System is the DP-100multi-function data processing system which appears in English and can gather data and measure the point, line, circle, angle and distance. The illumination of transmission and reflection is 24V/150W-halogen lamp. The power is 110V/ 220V(AC), 50/60HZ, and the total power is 400W. The cooling is the cold forced air cooling. The dimensions of this device is 1750*920*1700mm while the weight of the machine is 170kg.
YUYANG YYM-2010 Manual Video Measuring System is an ideal solution for industrial measurement applications. It is manufactured in DONGGUAN with a three-axis travel of 200*100 mm and a resolution of 0.001 mm. The measurement accuracy reaches up to ±3.5μm, and the dimension is 500*700*1100. The system is equipped with surface light and transmission light using LED, with brightness adjustable. It is especially perfect for profile projector and manual video measuring system.
The YUYANG YYM-2010 Manual Video Measuring System provides a reliable and accurate measurement solution for various industries. The high precision and resolution of this system ensures the accuracy and repeatability of the measurement results. It also features a user-friendly design with adjustable brightness and easy operation, making it an ideal choice for industrial measurement applications. With its high performance and durability, the YUYANG YYM-2010 Manual Video Measuring System is a great tool for measuring accurately and efficiently.
We provide technical support and service for Electrical Test Set. Our experienced technicians provide personalized service for each customer. We guarantee timely and reliable service to ensure that your Electrical Test Set is up and running as soon as possible.
We provide the following services:
We also provide technical support over the phone and through our online helpdesk. Our technicians are available 24/7 to answer your questions and walk you through any issues you may be having with your Electrical Test Set.
The Electrical Test Set is securely packaged to prevent any damage during transportation. The packaging material is designed to protect the product from any external impacts, dust, moisture, and other environmental conditions. The product is then shipped in a secure box or carton to its destination.
