Plastic Horizontal Burning Rate Test Apparatus ASTM D635 UL94 Plastic Flammability Testing Equipment

Plastic Horizontal Burning Rate Test Apparatus ASTM D635 UL94 Plastic Flammability Testing Equipment

ASTM D635 plastic flammability tester

UL94 horizontal burning rate apparatus

Plastic flammability testing equipment

Place of Origin:

China

Brand Name:

YUYANG

Certification:

CE

Model Number:

YY F056

Contact Us
Request A Quote
Plastic Horizontal Burning Rate Test Apparatus ASTM D635 UL94 Plastic Flammability Testing Equipment Plastic Horizontal Burning Rate Test Apparatus ASTM D635 UL94 Plastic Flammability Testing Equipment Plastic Horizontal Burning Rate Test Apparatus ASTM D635 UL94 Plastic Flammability Testing Equipment Plastic Horizontal Burning Rate Test Apparatus ASTM D635 UL94 Plastic Flammability Testing Equipment
Product Details
Bunsen Lamp:
Tube Diameter: 9.5mm ± 0.1mm
Test Inclination Angle Of Lamp:
0°, 45°, 90°, Quick Positioning; Max Travel Approx. 150mm
Test Gas:
98% Methane (reference Gas); Or Natural Gas Of 37MJ/m³ ±1MJ/m³
Ignition & Removal Time:
1s ~ 999.9s (digital Preset Available)
Flame Holding Time:
1s ~ 999.9s (digital Display, Non-preset)
Repeated Ignition Cycles:
1 ~ 9999 Times (digital Preset Available)
Power Supply:
0.5kVA, 220V, 50-60Hz
Highlight:

ASTM D635 plastic flammability tester

,

UL94 horizontal burning rate apparatus

,

Plastic flammability testing equipment

Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
$1620-1700
Packaging Details
Plywood Box
Delivery Time
7-30 Days
Payment Terms
L/C, D/A, D/P, T/T, Western Union
Supply Ability
200 sets per month
RELATED PRODUCTS
Good price Horizontal and Vertical Flammability Tester PV 3357 UL Standard Automotive Interior Material Burning Test Equipment online

Horizontal and Vertical Flammability Tester PV 3357 UL Standard Automotive Interior Material Burning Test Equipment

Get Best Price
Good price IEC60695-11-5 Needle Flame Tester HT-5169T-N Lab Flammability Testing Equipment for Electrical Appliance Safety Test online

IEC60695-11-5 Needle Flame Tester HT-5169T-N Lab Flammability Testing Equipment for Electrical Appliance Safety Test

Get Best Price
Good price Plastic Horizontal Burning Rate Test Apparatus ASTM D635 UL94 Plastic Flammability Testing Equipment online

Plastic Horizontal Burning Rate Test Apparatus ASTM D635 UL94 Plastic Flammability Testing Equipment

Get Best Price
Good price Ul94 Horizontal Vertical Burning Combustion Testing Machine Flame Test Chamber Flammability Tester for Plastic online

Ul94 Horizontal Vertical Burning Combustion Testing Machine Flame Test Chamber Flammability Tester for Plastic

Get Best Price
Contact Us
8613265296009
sales13@yuyangtest.com
86-769-26622869
Contact Now
Product Description
Plastic Horizontal Burning Rate Test Apparatus — ASTM D635 & UL94 Flammability Testing Equipment

This horizontal burning rate test apparatus is engineered for evaluating the flammability performance of plastic materials under controlled laboratory conditions. It supports standard horizontal burning tests in accordance with ASTM D635 and UL94 requirements, delivering repeatable, accurate burn-rate data for material qualification, quality control, and research and development.

Plastic horizontal burning rate test apparatus for ASTM D635 and UL94 flammability testing of plastic materials
Key Features
  • Horizontal specimen mounting configuration for standardized burn-rate measurement of plastic materials.
  • Compatible with ASTM D635 and UL94 horizontal burning test procedures.
  • Precise, adjustable specimen positioning for consistent flame application and reproducible results.
  • Robust, industrial-grade construction suited to continuous laboratory use.
  • Designed for straightforward operation, observation, and post-test measurement of burn distance and time.
Standards & Applications
Applicable Standards ASTM D635, UL94 (horizontal burning test)
Test Orientation Horizontal
Typical Materials Thermoplastics, plastic compounds, and polymer-based components
Typical Applications Material qualification, incoming and outgoing quality control, R&D flammability evaluation, and compliance verification
Why Choose This Flammability Testing Equipment

Reliable flammability data depends on controlled test conditions and stable apparatus performance. This horizontal burning rate test apparatus provides a dedicated, standards-aligned platform for plastic flammability testing, helping laboratories obtain consistent burn-rate results that support product safety, regulatory compliance, and material selection decisions.

For detailed technical specifications, chamber dimensions, and configuration options, please contact our technical team.
