Name: Precision Profile Projector Optical Comparator for Mechanical Parts & Thread Measurement
Brand: DONGGUAN YUYANG INSTRUMENT CO., LTD
SKU: YY-4025
Price: 3,000.00 USD
Availability: InStock

Home > Products > Horizontal Flammability Tester >

Precision Profile Projector Optical Comparator for Mechanical Parts & Thread Measurement

6 Station Horizontal Flammability Tester

0.85 m³ Test Room Horizontal Burning Test Apparatus

Digital Display Horizontal Flammability Tester

Place of Origin:

Guangdong

Brand Name:

YuYang

Certification:

Model Number:

YY-4025

Request A Quote

Product Details

Projection Screen:

Φ300 Mm

Magnification:

10X / 20X / 50X / 100X (Optional)

Worktable Travel:

(X×Y)150 × 50 Mm

Z-axis Travel:

80 Mm

Measuring Resolution:

0.001 Mm

Optical System:

Transmitted & Reflected Illumination

Light Source:

LED Cold Light Source

Display:

Digital DRO Display

Highlight:

6 Station Horizontal Flammability Tester

0.85 m³ Test Room Horizontal Burning Test Apparatus

Digital Display Horizontal Flammability Tester

Payment & Shipping Terms

Minimum Order Quantity

MOQ:1SET

Price

negotiate

Packaging Details

wooden box

Delivery Time

6-30 days

Payment Terms

L/C,D/A,D/P,T/T

Supply Ability

10 Set/Sets per Month

Horizontal Profile Projector Optical Comparator for Thread & Mold Contour Measurement

Get Best Price

Precision Profile Projector Optical Comparator for Mechanical Parts & Thread Measurement

Get Best Price

Horizontal Profile Projector | Optical Comparator for Precision Dimension Measurement

Get Best Price

Video

UL 94 Horizontal Vertical Flame Chamber , Safety 45 Degree Flammability Tester

Get Best Price

8618938576621

sales05@yuyangtest.com

86-769-26622869

Contact Now

Product Description

Horizontal Profile Projector | Optical Comparator for Precision Dimension Measurement

The horizontal profile projector is an optical comparator engineered for accurate, non-contact dimensional inspection of small and medium-sized workpieces. By projecting a magnified silhouette of the part onto a viewing screen, it enables operators to verify profiles, angles, threads, and surface features with high repeatability — making it a dependable instrument for quality control, tool rooms, and production inspection lines.

Key Measurement Capabilities

Non-contact optical measurement of length, diameter, angle, radius, and thread profiles
Magnified silhouette projection for fast visual comparison against overlay charts
Stable horizontal optical axis suited to shaft-type and elongated workpieces
Precise stage travel for repeatable coordinate positioning and dimension verification
Well-suited to incoming inspection, first-article checks, and in-process quality control

Typical Applications

Machined parts, turned components, and precision fasteners
Cutting tools, dies, molds, and stamping profiles
Threads, gears, and small plastic or metal molded parts
Electronics, watch components, and other miniature precision parts

Why Choose This Optical Comparator

The horizontal configuration provides a rigid, ergonomic platform for inspecting elongated parts while keeping the workpiece securely supported. Combined with clear silhouette imaging and precise stage movement, it delivers the measurement confidence required in industrial inspection environments — without the risk of surface contact or part deformation.
