Horizontal Profile Projector Optical Comparator for Thread & Mold Contour Measurement

Horizontal Profile Projector Optical Comparator for Thread & Mold Contour Measurement

50W 500W Test Flame Horizontal Flammability Tester

45° Test Dip Angle Horizontal Burning Test Apparatus

0.1s Combustion Timer Accuracy Horizontal Flammability Testing Equipment

Place of Origin:

Guangdong

Brand Name:

YuYang

Certification:

CE

Model Number:

YY-4025

Contact Us
Request A Quote
Horizontal Profile Projector Optical Comparator for Thread & Mold Contour Measurement Horizontal Profile Projector Optical Comparator for Thread & Mold Contour Measurement
Product Details
Projection Screen:
Φ300 Mm
Magnification:
10X / 20X / 50X / 100X (Optional)
Worktable Travel (X×Y):
150 × 50 Mm
Z-axis Travel:
80 Mm
Measuring Resolution:
0.001 Mm
Optical System:
Transmitted & Reflected Illumination
Highlight:

50W 500W Test Flame Horizontal Flammability Tester

,

45° Test Dip Angle Horizontal Burning Test Apparatus

,

0.1s Combustion Timer Accuracy Horizontal Flammability Testing Equipment

Payment & Shipping Terms
Minimum Order Quantity
MOQ:1SET
Price
negotiate
Packaging Details
wooden box
Delivery Time
6-30 days
Payment Terms
L/C,D/A,D/P,T/T
Supply Ability
10 Set/Sets per Month
RELATED PRODUCTS
Good price Horizontal Profile Projector Optical Comparator for Thread & Mold Contour Measurement online

Horizontal Profile Projector Optical Comparator for Thread & Mold Contour Measurement

Get Best Price
Good price Precision Profile Projector Optical Comparator for Mechanical Parts & Thread Measurement online

Precision Profile Projector Optical Comparator for Mechanical Parts & Thread Measurement

Get Best Price
Good price Horizontal Profile Projector | Optical Comparator for Precision Dimension Measurement online

Horizontal Profile Projector | Optical Comparator for Precision Dimension Measurement

Get Best Price
Good price UL 94 Horizontal Vertical Flame Chamber , Safety 45 Degree Flammability Tester online Video

UL 94 Horizontal Vertical Flame Chamber , Safety 45 Degree Flammability Tester

Get Best Price
Contact Us
8618938576621
sales05@yuyangtest.com
86-769-26622869
Contact Now
Product Description
Horizontal Profile Projector | Optical Comparator for Precision Dimension Measurement
Horizontal profile projector optical comparator used for precision dimensional measurement of machined and manufactured components

The horizontal profile projector is an optical comparator engineered for accurate, non-contact dimensional inspection of small and medium-sized workpieces. By projecting a magnified silhouette of the part onto a viewing screen, it enables operators to verify profiles, angles, threads, and surface features with high repeatability — making it a dependable instrument for quality control, tool rooms, and production inspection lines.

Key Measurement Capabilities
  • Non-contact optical measurement of length, diameter, angle, radius, and thread profiles
  • Magnified silhouette projection for fast visual comparison against overlay charts
  • Stable horizontal optical axis suited to shaft-type and elongated workpieces
  • Precise stage travel for repeatable coordinate positioning and dimension verification
  • Well-suited to incoming inspection, first-article checks, and in-process quality control
Typical Applications
  • Machined parts, turned components, and precision fasteners
  • Cutting tools, dies, molds, and stamping profiles
  • Threads, gears, and small plastic or metal molded parts
  • Electronics, watch components, and other miniature precision parts
Why Choose This Optical Comparator

The horizontal configuration provides a rigid, ergonomic platform for inspecting elongated parts while keeping the workpiece securely supported. Combined with clear silhouette imaging and precise stage movement, it delivers the measurement confidence required in industrial inspection environments — without the risk of surface contact or part deformation.
