White Drop Point Test Apparatus Lubricating Grease Testing Equipment

White Drop Point Test Apparatus Lubricating Grease Testing Equipment

  • White Drop Point Test Apparatus Lubricating Grease Testing Equipment
  • White Drop Point Test Apparatus Lubricating Grease Testing Equipment
White Drop Point Test Apparatus Lubricating Grease Testing Equipment
Product Details:
Place of Origin: CHINA
Brand Name: YUYANG
Certification: ISO
Model Number: DPT
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: USD700
Packaging Details: Plywood case
Delivery Time: 15 days
Supply Ability: 100 Sets per month
Contact Now
Detailed Product Description
Keyword: Dropping Point Apparatus Test Standard: ASTM D566
Power Supply: AC(220±10%)V, 50Hz Maximum Power Consumptio: 900W
Size: 350mm×180mm×410mm Warranty: 1 Year
Operation: Manual Color: White
High Light:

oil analysis machine

,

oil analyzer equipment

ASTM D566 Dropping Point Tester (Oil bath) Lubricating Grease Testing Equipment

Summary
The dropping point instrument is designed and made as per the national standard of People’s Republic of China GB/T 4929 Lubricating grease- Determination of Dropping Point and ASTM D566 Standard Test Method for Dropping Point of Lubricating Grease.

I. Main technical features
1. The oil bath is composed of heat resistant beaker, heater and electric motor. The heating power can be adjusted continuously. The temperature in oil bath is uniform..
2. Desktop structure. Easy to operate.

II. Main technical specifications
1. Power supply: AC 220 V±10%, 50 Hz
2. Oil bath: 600 ml beaker.
3. Grease cup: Made of chrome plated brass. Its inner diameter is about 9.92 mm and the diameter of orifice for dropping oil is 2.8 mm. The height of the cup is about 12 mm.
4. Test tube: A tube made of heat-resistant glass with rim. Its inner diameter is 11.1 mm to 12.7 mm. There are three indentations at about 19 mm from the bottom, equally spaced on the circumstance. These indentations are used for supporting the grease cup.
5. Thermometer: -5℃~300 ℃,scale value is 1 ℃. Its total length is 390 mm and the depth immersed is about 76 mm.
6. Heater: Tubular. Power 800 W.
7. Stirring motor: Rotating speed 60 RPM
8. Ambient temperature: -10℃~+40 ℃
9. Relative humidity: ≤85%
10. Maximum power consumption: 900 W
11. Dimension: 350mm×180mm×410mm

III.Accessories
No. Item Unit Qty Remarks
1 Grease cup Piece 2
2 Test tube Piece 2
3 Cork Piece 3
4 Guide ring Piece 2
5 Thermometer (-5℃to 300 ℃, and scale division is 1 ℃) Piece 3 The 3# is for dropping point
6 Metal rod Piece 1
7 Power supply wire (250 V 6 A) Piece 1
8 Stopping ring for thermometer (1#) Piece 4
9 5 A fuse (Φ5×20) Piece 2





White Drop Point Test Apparatus Lubricating Grease Testing Equipment 0
