Stability Laboratory + 80 ℃ Humidity Test Chamber

Stability Laboratory + 80 ℃ Humidity Test Chamber

Stability Laboratory + 80 ℃ Humidity Test Chamber
Stability Laboratory + 80 ℃ Humidity Test Chamber
Stability Laboratory + 80 ℃ Humidity Test Chamber
Product Details:
Place of Origin: CHINA
Brand Name: YUYANG
Certification: IEC60068-2-1, IEC60068-2-2, GJB150.3, GJB150.4, GJB150.9
Model Number: YYE006
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiation
Packaging Details: Wooden Box
Delivery Time: 1-3 WORK DAYS
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 SETS A MONTH
Contact Now
Detailed Product Description
Blackboard Temperature Range: Room Temperature 30 ℃ ~ + 80 ℃ Shell Material: Stainless Steel 304 / Coating
Light Source:: 1.0 KW Net Weight:: 110 Kg
Dimensions: 400*500*500(mm) Power: AC 220V/50HZ
High Light:

thermal shock test chamber

,

salt spray test chamber

Laboratory High Low Temperature Humidity Control Stability Test Environmental Chamber



30 ℃ ~ + 80 ℃ High Low Temperature Humidity Test Chamber IEC60068-2-1



Description



Laboratory High Low Temperature Humidity Control Stability Test Environmental Chamber is used to test the material characteristic for wire type, skin type, plastic, rubber, cloth, Equiped with a special ventilation regulator for maintain the fresh air inside when heating. This testing machine design with sophisticated air-displacement adjustment device and a digital voltage meter, current meter, watt-hours, the timer can be used to measure the air replacement rate. Horizontal circulatory air supply system and both sides of airflow regulator to ensure the internal temperature uniformity and stability.





Main technical parameters





Temperature range: 0 ℃ -150 ℃; -20 ℃ -150 ℃; -40 ℃ -150 ℃ ; -60 ℃ -150 ℃; -70 ℃ -150 ℃



Temperature fluctuation: ± 0.5 ℃ (without load) Temperature deviation: ≤ ± 2 ℃ Average temperature of temperature rise and fall: 0.7 ℃ ~ 1.0 ℃ / min (without load) Time setting range: 0 ~ 9999 hours Power requirements: AC380V





Features:





1. High-texture appearance, the surface handled through the matte stripes, and use of planar non-reactive handles, easy to operate, safe and reliable.
2. Rectangular complex glass window can be viewed the testing sample, windows with anti-sweat heater device that prevents water vapor condensation, and high-brightness PL light.
3. Double-insulated airtight container, which can effectively isolate the internal temperature of leakage.
4. With an external water supply system can be easy to supply water and automatically reuse.
5. Compressor circulatory system from French and use environmentally refrigerants ( R404).
6. PLC controller, touch screen import and display the measure values and curve
7. Controller with multi-segment program edited, temperature and humidity can be controlled quickly (OUICK) or slope (SLOP).
8. Built-in mobile pulley easy to move and has a strong positioning screw fixed position





Main Technical Parameter



Structure





Chambers is designed as a unitary structure. The upper part of the chamber is the test area, the compressor section is at the bottom and the electrical control cabinet is the right part of the tester, featured with rational design and durable.





Housing



The tester housing is made of high-quality galvanized sheet processed by CNC machine, undergoing spray plastic treatment, smooth and good appearance;





Chamber





The chamber is made by high quality SUS304 stainless steel plate;





Sample rack





Two layers of stainless steel sample racks as standard supply; Load: Not more than 25 kg.





Insulation material





High-density glass fiber cotton. Insulation layer thickness is 100mm.



Inspection window



The window is made by multi-layered tempered glass, lined with binding conductive coating, featured with transparent, heat insulation, less steam and frost resistant and other advantages;



Mixing system



The long axis fan motor and multi-blades impeller with good low and high temperature resistance are used.



Door





The door inner plate is made by stainless steel. And adopt non-reaction door handle, Easy operation;



Sealing strip





The door and chamber body are sealed by high elastic double layer seal, with high temperature resistance.



Test hole



The left side is set a φ50mm test hole for external test power supply cable or signal cable (hole size or hole quantity to be decided by the user). The hole is equipped with a special soft rubber plug and stainless steel cover.









Packaging Details



1.First packed with stretch film to keep it clean,
2.Then use paper angle bead to make it safe,
3.Next use bubble bag to make double protect,
4.Last packed it with fumigation wooden case.



 Stability Laboratory + 80 ℃ Humidity Test Chamber 0Stability Laboratory + 80 ℃ Humidity Test Chamber 1

Stability Laboratory + 80 ℃ Humidity Test Chamber 2
