Name: Xenon Aging Chamber With Irregularly Shaped Sample Holder For Environmental Test Chamber
Brand: DONGGUAN YUYANG INSTRUMENT CO., LTD
SKU: YY833
Price: 11957.00 USD
Availability: InStock

Home > products > Environmental Test Chamber >

Xenon Aging Chamber With Irregularly Shaped Sample Holder For Environmental Test Chamber

Environmental Test Xenon Aging Chamber

Irregularly Shaped Xenon Aging Chamber

Place of Origin:

CHINA

Brand Name:

YUYANG

Certification:

ISO5470

Model Number:

YY833

Request A Quote

Xenon Aging Chamber With Irregularly Shaped Sample Holder For Environmental Test Chamber

Product Details

Shell Material:

Stainless Steel 304 / Coating

Net Weight::

110 Kg

Overall Dimensions:

925 * 487 * 487 Mm

Power:

AC 220V/50HZ

Controller:

Programmable PLC Touch Screen

Angle Tolerance:

≤5°

External Dimension:

Customized

Controller Resolution:

±0.3℃；±2.5%RH

Humidity:

85%~98%RH

Working Room Space:

450×1170×50mm

Highlight:

Environmental Test Xenon Aging Chamber

Irregularly Shaped Xenon Aging Chamber

Payment & Shipping Terms

Minimum Order Quantity

Price

negotiation

Packaging Details

Wooden Box

Delivery Time

1-3 WORK DAYS

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

500 SETS A MONTH

Constant Environmental Cycling Control High-low Temperature Climatic Chamber With Controlled Temperature and Humidity

Get Best Price

Video

Lab Supplies Programmable Constant Temperature Humidity Chamber Test Equipment

Get Best Price

UV Aging Test Lamp For Bituminous Materials With 220v Voltage Current Power Monitor Power Factor Frequency Energy Meter

Get Best Price

Customizable ODM OBM Electronic Salt Fog Corrosion Test Device With Temperature Control Meter 1.0-6.0

Get Best Price

86-769-26622869

Contact Now

Product Description

Xenon Aging Chamber With Irregularly Shaped Sample Holder For Environmental Test Chamber

Description:

Xenon Aging Chamber Environment Accelerated Aging Chamber is analogue terrestrial solar radiation environment, widely used to determine the electrical, electronic products shell, leather and other light on the atmospheric environment adaptability; also be used to examine the effect of solar radiation on the ground equipment and components produced (thermal, mechanical, , chemical, electrical, etc.)

Structural characteristics:

A variety of alternative filtration system.
Water spray function.
Relative humidity control.
Chamber air temperature control system.
Irregularly shaped sample holder.
Cheap xenon arc lamps.
Xenon lamp aging test instrument easy to install and easy to use and basically no routine maintenance.
Xenon arc lamp life depends on the level of irradiance used, general lamp life of 1600 hours. Lamp replacement convenient, long-lasting xenon lamp aging tester filter to maintain the required spectrum to provide protection.

Specifications:

light source	1.8 KW original Q - Lab import air cooled xenon lamp or 1.8 KW domestic xenon lamp (normal life 1500 hours)
filters	filters or the sun glass filter (optional)
effective exposure area	1000 cm2 (a 150 x 70 mm model 9)
light irradiance range	30 w/m2 ~ 100 w/m2 (300 nm to 400 nm) Or 0.35 W/m2 ~ 0.7 W/m2 (@ 340 nm) Or 0.5 W/m2 ~ 2.1 W/m2 (@ 420 nm)
blackboard temperature range	room temperature 30 ℃ ~ + 80 ℃
shell material	stainless steel 304 / coating
overall dimensions	925 * 487 * 487 mm (length x width x height)
net weight	110 kg (including packaging wooden box 140 kg)
power supply	220 v, 50/60 hz;Maximum current 12 A

Xenon Aging Chamber With Irregularly Shaped Sample Holder For Environmental Test Chamber 0
