ISO5627 AC220V Bekk Paper / Pakage Smoothness Test Equipment (380±1)ml

ISO5627 AC220V Bekk Paper / Pakage Smoothness Test Equipment (380±1)ml

packaging testing instruments

compression test equipment

Place of Origin:

China

Brand Name:

YUYANG

Certification:

ISO 5627, GB/T456, QB/T1665

Model Number:

YYP-017

Contact Us
Request A Quote
Product Details
Measure Range:
(1~9999)S
Timing Accuracy Time:
1000S
Vacuum Vessels Big Vacuum Container::
(380±1)ml
Small Vacuum Container::
(38±1)ml
Contact Pressure:
(100±2)kPa
Vacuum Accuracy:
±0.07kPa
Dimensions:
300×370×420mm
Power:
AC220V,50Hz
Highlight:

packaging testing instruments

,

compression test equipment

Payment & Shipping Terms
Packaging Details
plywood case
Delivery Time
3-5 work days
Supply Ability
800 Set/Sets per Month
Product Description



ISO5627 AC 220V Bekk Paper / Pakage Smoothness Test Equipment (380±1)ml





Product Description:


Bekk Paper / Pakage Smoothness Test Equipment is a new type tester developed by our company according to the ISO standards. This instrument is mainly used to test the smoothness of the paper or cardboard (by Bekk method). Bekk smoothness: Time in seconds which under a defined pressure differential is required to draw a definite quantity of air at atmospheric pressure between the surface of the test piece and a ring-shaped plane surface under specified conditions of contact. The smoothness of a wide range of paper and boards may be measured by this method and it is especially recommended for smooth papers and boards. However, for very smooth samples, measurement times may be impractically long.





Main Features:



1.Imported Oil-free vacuum pump,can work without oil

2.Fast measurement:can choose a small volume chamber measurement, measurement time is only one-tenth of a large volume chamber, saving time in measurement.and the function of"automatic test" has been added in , can greatly save time when testing high smoothness.sample

3.Good seal: adopted foreign vacuum sealed plastic and advanced sealing technology to achieve the national standard requirements;

4. Adopted 7.0 inches color touch-screen which makes it easy to operate.

5.Instrument has strong data processing ability, can be directly the statistical results of the data.

6.Adopted CAM and spring structure design, when measuring the single chip microcomputer automatically control synchronous motor rotating ,load pressure and clip paper

7.Data communication: by buying the PC software, the instrument can be connected via USB cable to communicate with the computer.





Standards:



ISO 5627 GB/T456  QB/T1665





Specifications:



ITEM Specification
Power supply: AC220V±10% 50HZ
Precision: 0.1s
Measuring range: 10±0.05cm2
Pressure: 100kpa±2kpa
Display: English menu and LCD screen
Printer : thermal printing, high speed and no noise.
Communication output: standard RS232 interface
Ambient conditions: temperature 10~30 degree. Relative humidity<85%
External dimensions and weight: Length × Width × Height: ?318mm×362mm×518mm, 35kg
